Product Overview
The Bently Nevada 3500/94M 145988-01 Keyphasor Module is part of the 3500 Machinery Protection and Condition Monitoring System.
It is designed to receive, condition, and process Keyphasor signals from rotating machinery, providing the system with a precise phase reference and speed measurement signal.
A Keyphasor signal is a once-per-turn (or multi-per-turn) pulse generated by a proximity probe, magnetic pickup, or optical sensor mounted near the machine shaft.
This signal is used by other 3500 monitor modules (such as the 3500/42M, 3500/50, and 3500/60) to measure vibration phase, rotational speed, and shaft position.
The 3500/94M module features two independent channels, each capable of accepting and conditioning separate Keyphasor inputs for multi-shaft or redundant systems.
Key Features
-
Accepts up to two independent Keyphasor inputs.
-
Supports proximity probes, magnetic pickups, and optical sensors.
-
Provides phase reference and speed pulse to other rack modules.
-
Fully configurable through Bently Nevada 3500 Configuration Software.
-
Dual-channel operation for redundant or dual-shaft machines.
-
Front-panel LEDs for OK, Channel OK, and TX/RX indication.
-
High accuracy and stability for industrial environments.
-
Designed in accordance with API 670 standards for machinery protection.
Technical Specifications
| Parameter | Specification | Description / Notes |
|---|---|---|
| Model Number | 3500/94M | Keyphasor Module |
| Part Number | 145988-01 | Dual-channel monitor module |
| System Compatibility | Bently Nevada 3500 Rack | Full-height module |
| Number of Channels | 2 independent channels | For dual Keyphasor inputs |
| Input Type | Proximity probe, magnetic pickup, or optical sensor | Configurable |
| Input Signal Range | ±20 V peak | Max input amplitude |
| Frequency Range | 1 to 20,000 RPM (typical) | Dependent on probe type |
| Signal Conditioning | Adjustable threshold and gain | Optimized pulse formation |
| Output Data | Phase reference, Keyphasor pulse, speed | Shared to 3500 rack |
| Isolation | Channel-to-channel and channel-to-backplane isolation | Reduces electrical noise |
| Configuration Tool | Bently Nevada 3500 Configuration Software | Setup and diagnostics |
| Power Consumption | Approx. 7 W | Typical load |
| Operating Temperature Range | –30 °C to +65 °C | Continuous duty |
| Storage Temperature Range | –40 °C to +85 °C | Non-operating |
| Relative Humidity | 5–95% non-condensing | Industrial environment |
| Dimensions (H × W × D) | 241.3 × 24.4 × 241.8 mm (9.50″ × 0.96″ × 9.52″) | Full-height module |
| Weight | Approx. 0.9 kg (2.0 lb) | Typical |
| Mounting Type | Full-height slot in 3500 rack | Rear I/O interface |
| LED Indicators | OK, Channel OK, TX/RX | Front panel |
| Compliance | API 670, CE, CSA, ATEX | International standards |
Bently Nevada 3500/94M 145988-01 Keyphasor Module is in stock. Please contact us for a quick quote and competitive pricing.
