Bently Nevada 9200-01-01-01-00 Two-Wire Velocity Seismoprobe Transducer
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Two-Wire Velocity Seismoprobe Transducer |
| Product Model | 9200-01-01-01-00 |
| Manufacturer | Bently Nevada |
| Series | 9200 |
| Measurement Principle | Moving-coil velocity transducer |
| Mounting Angle | 0° ±2.5° |
| Minimum Operating Frequency | 4.5 Hz (270 CPM) |
| Sensitivity | 20 mV/mm/s (500 mV/in/s), ±5% |
| Frequency Response | 4.5 to 1,000 Hz typical |
| Connector | Top mount, no integral cable |
| Mounting Base | Circular base with 1/4-20 UNC stud |
| Coil Resistance | 1.25 kΩ ±5% |
| Locked Coil Inductance | 125 mH typical |
| Calibration Load | 10 kΩ |
| Dynamic Operating Range | 2.54 mm (0.100 in) peak-to-peak maximum displacement |
| Velocity Range | Up to 25 mm/s (1 in/s) under specified reference conditions |
| Shock Resistance | Up to 50 g peak on the non-sensitive transverse axis |
| Operating Temperature | −29°C to +121°C (−20°F to +250°F) |
| Relative Humidity | Up to 95%, non-condensing |
| Dimensions | Approx. 102 mm length × 41 mm diameter |
| Weight | Approx. 0.30 kg |
| Agency Approval | None; suffix 00 |
FAQ
Q: What is the 9200-01-01-01-00 used for?
A: It is a two-wire velocity transducer designed for measuring vibration velocity on industrial machinery, including bearing housings, machine casings, and structural components.
Q: What measurement technology does this transducer use?
A: The 9200 uses a moving-coil design. It generates an electrical output proportional to the vibration velocity being measured.
Q: What is the sensitivity of the 9200-01-01-01-00?
A: Its nominal sensitivity is 20 mV/mm/s, equivalent to 500 mV/in/s, with a typical tolerance of ±5%.
Q: What is the frequency range of this model?
A: The specified minimum operating frequency is 4.5 Hz, with the upper frequency limit extending to approximately 1,000 Hz under typical conditions.
Q: How is the 9200-01-01-01-00 mounted?
A: This configuration uses a circular mounting base with a 1/4-20 UNC stud. The transducer mounting angle is 0° ±2.5°.
Q: Does the 9200-01-01-01-00 require an external power supply?
A: No. The moving-coil velocity transducer is self-generating and does not require a separate excitation power supply for its sensing element.
Q: What environmental temperature can this model withstand?
A: The normal operating temperature range is approximately −29°C to +121°C (−20°F to +250°F).
Q: What should be checked when replacing a 9200-01-01-01-00?
A: Verify the mounting thread, top-mounted connector arrangement, sensitivity, minimum frequency, cable configuration, and compatibility with the connected vibration monitoring system before installation.
Bently Nevada 9200-01-01-01-00 Two-Wire Velocity Seismoprobe Transducer is in stock. Please contact us for a quick quote and competitive pricing.
