Bently Nevada AAP1407030-00100 Vibration Probe
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Vibration Probe |
| Manufacturer | Cameron / Ingersoll Rand |
| Product Model | AAP1407030-00100 |
| Part Number | AAP1407030-00100 |
| Application | Rotating Machinery Vibration Monitoring |
| Sensor Type | Eddy-Current Proximity / Vibration Probe |
| Measurement Principle | Non-contact eddy-current displacement measurement |
| Probe Diameter | Approx. 8 mm |
| Probe Thread | M8 × 1 |
| Typical Measurement Range | 0–2.0 mm (0–0.08 in) |
| Output Signal | 4–20 mA DC |
| Cable Length | Approx. 0.5 m |
| Connector | Miniature coaxial ClickLoc connector |
| Power Supply | 24 VDC ±10% |
| Maximum Load Resistance | ≤500 Ω |
| Operating Temperature | -40°C to +125°C |
| Maximum Thread Engagement | 12 mm |
| Mounting | Threaded / reverse-mount configuration |
| Typical Application | Compressor shaft vibration and displacement monitoring |
| Compatible Equipment | Cameron / Cooper centrifugal compressors |
| Dimensions | Approx. 205 × 225 × 35 mm* |
| Weight | Approx. 0.20 kg* |
*Published dimensions may refer to the supplied product or package configuration rather than the bare probe body. Actual physical dimensions should be verified against the equipment drawing before installation.
FAQ
Q: What is the AAP1407030-00100 used for?
A: AAP1407030-00100 is a vibration probe intended for monitoring shaft vibration and displacement in rotating machinery, particularly centrifugal compressor applications.
Q: What sensing technology does it use?
A: It uses eddy-current proximity sensing. The probe measures changes in the distance between its sensing tip and a conductive shaft without making physical contact.
Q: What is the probe thread size?
A: The listed configuration uses an M8 × 1 threaded probe housing, with a maximum thread engagement of approximately 12 mm.
Q: What is the typical measurement range?
A: The listed measurement range is approximately 0–2.0 mm (0–0.08 in). The effective operating range depends on the complete sensing system and installation conditions.
Q: What output signal does the probe provide?
A: The specified configuration provides a 4–20 mA DC output for connection to compatible compressor control, monitoring, or instrumentation systems.
Q: What power supply is required?
A: The listed supply requirement is 24 VDC ±10%, with a maximum recommended load resistance of approximately 500 Ω.
Q: What equipment is this probe commonly used with?
A: It is primarily associated with Cameron/Cooper centrifugal compressors and is used for monitoring shaft vibration or displacement during machine operation.
Q: What are the dimensions and weight?
A: The commonly listed overall dimensions are approximately 205 × 225 × 35 mm, with a weight of about 0.20 kg. Because supplier dimensions can include the supplied assembly or packaging, the equipment drawing should be used when precise installation dimensions are required.
Bently Nevada AAP1407030-00100 Vibration Probe is in stock. Please contact us for a quick quote and competitive pricing.
