Emerson KJ3002X1-BA1 12P0680X122 Analog Output Modules
Product Overview
The Emerson KJ3002X1-BA1 12P0680X122 Analog Output Module is designed to provide precise analog output for process control systems in industrial automation. This module is engineered for integration into Emerson’s DeltaV™ distributed control system (DCS) and is ideal for applications requiring high reliability and accuracy. It supports a variety of field devices, delivering accurate control and monitoring of industrial processes. Its compact form and robust design make it suitable for harsh industrial environments, where performance and uptime are critical.
The KJ3002X1-BA1 module offers high-resolution output, reducing signal drift and ensuring process stability, and is equipped with advanced diagnostics for effective maintenance and troubleshooting.
Key Features
-
High-Resolution Output: Provides up to 16-bit resolution, ensuring precise control and minimal signal drift.
-
Wide Output Range: Supports standard 4-20 mA, 0-10 V DC, and other industry-standard output ranges.
-
Robust Diagnostics: Includes diagnostics for real-time monitoring and fast fault detection, reducing downtime.
-
Compact and Modular: Easily integrates into existing systems and is designed for space-efficient installation in control panels.
-
High Reliability: Designed for continuous operation in demanding industrial environments.
-
Compatibility: Fully compatible with Emerson’s DeltaV™ system and other compatible automation platforms.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 38 x 125 x 114 mm |
| Weight | 0.2 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Model | KJ3002X1-BA1 |
| Manufacturer | Emerson |
| Installation | DIN Rail Mountable |
| Power Supply | 24 V DC |
| Operating Temp | -20°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
3.3 Output Characteristics
| Item | Specification |
|---|---|
| Output Type | Analog (4-20 mA, 0-10 V DC) |
| Resolution | 16-bit |
| Output Range | 4-20 mA, 0-10 V DC |
| Output Current | 4-20 mA |
| Output Voltage | 0-10 V DC |
| Load Resistance | 250 Ω (for current output), ≥ 10 kΩ (for voltage output) |
| Response Time | < 50 ms |
3.4 Electrical Characteristics
| Item | Specification |
|---|---|
| Power Consumption | < 2 W |
| Isolation Voltage | Up to 1500 Vrms |
| Channel Isolation | 1500 Vrms |
Industry Applications
-
Process Control: Widely used in chemical, pharmaceutical, and petrochemical industries for controlling flow, pressure, and temperature.
-
Energy & Power Generation: Supports power plant control systems by providing analog output for key process variables.
-
Water & Wastewater Treatment: Ensures accurate monitoring and control of water treatment processes, including pH, chlorine, and flow rate.
-
Manufacturing Automation: Used in automated production lines for precise control of automated systems.
-
HVAC Systems: Provides control signals for heating, ventilation, and air conditioning systems in commercial and industrial facilities.
The Emerson KJ3002X1-BA1 12P0680X122 Analog Output Module is a versatile and reliable solution for controlling and monitoring industrial processes. With its high resolution, robust diagnostics, and flexible output capabilities, it is an ideal choice for applications requiring high precision and continuous operation in demanding environments.
Emerson KJ3002X1-BA1 12P0680X122 Analog Output Modules is in stock. Please contact us for a quick quote and competitive pricing.
