Emerson KL3103X1-LS1 Digital Input Characteristic Module
Product Overview
The Emerson KL3103X1-LS1 is a Digital Input Characterization Module (CHARM) designed for use within Emerson’s DeltaV™ Electronic Marshalling system. It enables direct connection of discrete field devices such as limit switches, push buttons, and relay contacts to the DeltaV system. The module features a single-channel digital input with built-in signal conditioning and electrical isolation, ensuring accurate signal capture even in electrically noisy industrial environments. This CHARM module simplifies field wiring, enhances flexibility, and supports hot-swapping for efficient maintenance.
Key Features
-
Single-Channel Digital Input – Accepts standard 24 VDC discrete input signals
-
CHARM Technology – Offers plug-and-play flexibility and channel-level characterization
-
Galvanic Isolation – Isolates field wiring from control system for increased safety and signal integrity
-
Hot-Swappable Design – Allows replacement without disrupting system operation
-
Auto Detection – Automatically recognized by DeltaV for seamless configuration
-
Compact and Modular – Easily integrates into CHARM I/O cards and terminal blocks
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 120 x 150 x 45 mm |
| Weight | 0.5 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Input Type | Digital (discrete 24 VDC) |
| Input Voltage Range | 18–30 VDC |
| Input Current | 2.5 mA typical |
| Logic Threshold | ON > 15 VDC, OFF < 5 VDC |
| Isolation Voltage | ≥1500 V RMS (field to system logic) |
| Power Supply | Provided via CHARM baseplate |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | -40°C to +70°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Protection Rating | IP20 (when installed in enclosure) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| System Platform | Emerson DeltaV with CHARMs |
| Compatible I/O Baseplate | CHARM I/O Card and Terminal Block |
| Module Type | Digital Input CHARM |
Industry Applications
-
Manufacturing Automation – Monitors machine status, operator inputs, and safety devices
-
Oil & Gas – Captures digital signals from alarms, sensors, and field switches
-
Power & Energy – Interfaces with protective relays and control logic circuits
-
Water & Wastewater – Detects valve positions, pump states, and process alarms
-
Pharmaceutical and Food Processing – Ensures reliable operation of cleanroom controls and batch processes
The Emerson KL3103X1-LS1 Digital Input CHARM module delivers dependable performance for digital signal acquisition in modern DeltaV control systems. Its flexibility, isolation, and hot-swap capability make it ideal for efficient, scalable, and robust I/O deployment across various industries.
