Emerson TREXLFPKLWS3S AMS Trex Device Communicator – AMS Trex Series
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Emerson |
| Product Type | HART and FOUNDATION Fieldbus Device Communicator |
| Product Model | TREXLFPKLWS3S |
| Product Series | AMS Trex Device Communicator |
| Communication Module | L – Device Communicator Plus |
| Applications | F – HART + FOUNDATION Fieldbus |
| Power Module | P – Rechargeable Li-Ion Power Module |
| Safety Certification | KL – ATEX, CSA (US/Canada) and IECEx Intrinsically Safe |
| Wireless | W – Bluetooth, Wi-Fi and NFC |
| Support | S3 – Standard Support, 3 Years |
| Display | 5.7-inch color VGA resistive touchscreen, 640 × 480 pixels |
| Processor | 800 MHz ARM Cortex-A8 / NXP |
| RAM | 512 MB DDR3 SDRAM |
| Internal Storage | 2 GB NAND + 32 GB extended flash |
| Operating System | Windows Embedded Compact 2013 |
| HART Communication | Supported |
| FOUNDATION Fieldbus | Supported |
| HART Loop Power | 3–22.5 mA |
| FF Power Capability | 0–38 mA |
| Wireless Interfaces | Bluetooth 2.1, Wi-Fi 802.11 b/g/n, NFC |
| Enclosure Rating | IP54 |
| Operating Temperature | -20 to +55°C; -20 to +50°C for intrinsically safe operation |
| Battery | Rechargeable Lithium-Ion |
| Operating Time | 8+ hours typical |
| Dimensions (L × W × H) | Approx. 260 × 115 × 60 mm |
| Weight | Approx. 1.33 kg |
| Magnet | No |
FAQ
Q: What is the Emerson TREXLFPKLWS3S?
The TREXLFPKLWS3S is an AMS Trex Device Communicator configured for both HART and FOUNDATION Fieldbus applications.
Q: What do the letters in TREXLFPKLWS3S mean?
TREX identifies the base platform, L indicates the Device Communicator Plus module, F provides HART and FOUNDATION Fieldbus applications, P specifies the rechargeable Li-Ion power module, KL identifies the intrinsic-safety approvals, W indicates wireless connectivity, and S3 provides three-year standard support.
Q: Can the TREXLFPKLWS3S power a HART device?
Yes. Its Device Communicator Plus module provides HART loop power and supports a current range of approximately 3–22.5 mA for bench-level device work.
Q: Does the TREXLFPKLWS3S support FOUNDATION Fieldbus?
Yes. It supports FOUNDATION Fieldbus device communication and can provide fieldbus power for suitable bench applications.
Q: What wireless functions are included?
The W configuration includes Bluetooth, Wi-Fi and NFC connectivity for wireless data transfer and device-related workflows.
Q: Is the TREXLFPKLWS3S intrinsically safe?
Yes. The KL configuration provides ATEX, CSA for the US/Canada, and IECEx intrinsic-safety certifications, including FISCO where applicable.
Q: Does the TREXLFPKLWS3S have a battery?
Yes. Unlike many fixed industrial modules, this handheld communicator uses a rechargeable lithium-ion power module and provides more than 8 hours of typical operating time.
Q: Does the TREXLFPKLWS3S contain a magnet?
No. The communicator does not contain a permanent magnet as a primary component.
Emerson TREXLFPKLWS3S AMS Trex Device Communicator – AMS Trex Series is in stock. Please contact us for a quick quote and competitive pricing.
