Emerson VE3008 DeltaV™ CHARMS Baseplate Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | DeltaV™ CHARMS Baseplate Module |
| Model | VE3008 |
| System Compatibility | Emerson DeltaV™ Electronic Marshalling (CHARMS) |
| Function | Houses and interfaces CHARM I/O modules |
| Channel Capacity | Supports up to 8 individual CHARM modules |
| Communication Bus | Redundant I/O subsystem backplane |
| Power Requirement | Powered through system carrier |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5%–95% non-condensing |
| Material | Industrial-grade reinforced composite |
| Dimensions (L×W×H) | 140 mm × 95 mm × 52 mm |
| Weight | 0.45 kg |
| Mounting Type | DIN-rail or panel-mounted |
| Application | Modular I/O infrastructure for distributed control |
FAQ
- Q1: What is the primary role of the VE3008 module?
A: It serves as the baseplate for mounting and connecting up to eight DeltaV CHARM modules within an electronic marshalling system. - Q2: Is the VE3008 compatible with all DeltaV CHARM types?
A: Yes, it is designed to support the full range of CHARM signal types used in field I/O applications. - Q3: Does this baseplate include internal power distribution?
A: Power is supplied through the system carrier, ensuring consistent power distribution to each mounted CHARM module. - Q4: Can the VE3008 be mounted on standard DIN rails?
A: Yes, it supports DIN-rail as well as panel mounting configurations. - Q5: What environments is the module rated for?
A: It is suitable for industrial conditions ranging from -20°C to 60°C and high humidity environments. - Q6: How many channels does each baseplate support?
A: The VE3008 accommodates up to 8 CHARM modules, each representing one I/O channel. - Q7: Does the module support redundant communication?
A: Yes, it interfaces with redundant backplane communication paths within the DeltaV architecture. - Q8: How heavy is the VE3008 baseplate?
A: The unit weighs approximately 0.45 kg, allowing for easy installation even in dense control cabinets.
Emerson VE3008 DeltaV™ CHARMS Baseplate Module is in stock. Please contact us for a quick quote and competitive pricing.
