Epro PR6423/010-010-CN+CON021/914-100 Eddy Current Displacement Measurement System
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Specification | Details |
|---|---|
| Product Model | PR6423/010-010-CN + CON021/914-100 |
| Product Type | Eddy Current Displacement Measurement System (Probe + Signal Converter) |
| Manufacturer | EPRO / Emerson |
| Series | PR6423 Series + CON021 Converter |
| Main Function | Non-contact measurement of shaft displacement, vibration, position, eccentricity, and rotational speed |
| Application | Steam turbines, gas turbines, hydro turbines, compressors, pumps, fans, gearboxes, rotating machinery condition monitoring |
| System Components | PR6423/010-010-CN Eddy Current Probe + CON021/914-100 Signal Converter |
| Sensor Type | Eddy Current Proximity Sensor |
| Sensor Diameter | 8 mm |
| Probe Structure | Standard Mount Configuration |
| Measuring Principle | Eddy current non-contact displacement measurement |
| Linear Measuring Range | 2 mm |
| Static Measuring Range | ±1 mm |
| Dynamic Measuring Range | 0 to 500 μm |
| Initial Air Gap | Approx. 0.5 mm |
| Sensitivity | 8 V/mm |
| Linearity Error | ≤ ±1% |
| Frequency Response | 0…20 kHz |
| Target Material | Ferromagnetic steel |
| Minimum Shaft Diameter | ≥25 mm |
| Cable Length | According to ordering code configuration |
| Connector Type | LEMO connector |
| Cable Material | PTFE |
| Probe Tip Material | PEEK |
| Housing Material | Stainless steel |
| Probe Operating Temperature | -35°C to +180°C |
| Short-Term Temperature | Up to +200°C |
| Protection Class (Probe) | IP66 |
| Installation Type | Non-contact installation |
| Mounting Thread | M10 × 1 |
| Converter Model | CON021/914-100 |
| Converter Function | Converts eddy current probe signal into standardized displacement output |
| Converter Compatibility | EPRO PR6423 series measurement systems |
| Converter Frequency Response | 0…20 kHz |
| Converter Rise Time | <15 μs |
| Converter Operating Temperature | -30°C to +100°C |
| Converter Protection Class | IP20 |
| Converter Supply Voltage | DC power supply |
| Converter Output Signal | Standard displacement voltage output |
| Converter Mounting | Cabinet / panel mounting |
| Typical Applications | Turbine shaft vibration monitoring, rotor displacement measurement, bearing monitoring, machinery protection systems |
FAQ
Q1: What is the PR6423/010-010-CN+CON021/914-100 mainly used for?
A: It is a complete EPRO eddy current displacement measurement system used for non-contact monitoring of shaft displacement, vibration, eccentricity, position, and operating condition in rotating machinery.
Q2: What components are included in this model?
A: The system includes the PR6423/010-010-CN 8 mm eddy current probe and the CON021/914-100 signal converter.
Q3: Does the PR6423/010-010-CN require contact with the shaft?
A: No. It uses eddy current technology to measure the distance between the probe tip and the rotating shaft without mechanical contact.
Q4: What equipment can use this system?
A: It is commonly used in steam turbines, gas turbines, hydro turbines, compressors, pumps, fans, gearboxes, and other critical rotating machinery.
Q5: What is the function of the CON021/914-100 converter?
A: The converter processes the eddy current probe signal and converts it into a standardized displacement output for PLC, DCS, vibration monitoring systems, and machinery protection systems.
Q6: What is the difference between PR6423/010-010-CN and PR6423/010-010-CN+CON021/914-100?
A: PR6423/010-010-CN is the sensor probe only. The +CON021/914-100 version includes the matching signal converter to form a complete measurement system.
Q7: What are the advantages of this system?
A: It provides high accuracy, fast response, non-contact measurement, high-temperature resistance, and reliable operation in harsh industrial environments.
Q8: Where is it typically installed?
A: It is typically installed near turbine or compressor shafts to monitor rotor displacement, vibration, eccentricity, and machine operating condition.
Epro PR6423/010-010-CN+CON021/914-100 Eddy Current Displacement Measurement System is in stock. Please contact us for a quick quote and competitive pricing.
