Epro PR6424/000-121 Eddy Current Displacement Sensor
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | PR6424/000-121 |
| Product Type | Eddy Current Displacement Sensor |
| Manufacturer | EPRO / Emerson |
| Series | PR6424 Series |
| Main Function | Non-contact measurement of shaft displacement, vibration, axial position, eccentricity, and speed in rotating machinery |
| Sensor Type | 16 mm Eddy Current Probe |
| Measurement Principle | Eddy current non-contact measurement |
| Measuring Range | 4 mm |
| Static Measuring Range | ±2 mm |
| Dynamic Measuring Range | 0 to 1000 μm |
| Sensitivity | 4 V/mm |
| Initial Air Gap | Approx. 2.7 mm |
| Linearity Error | ≤ ±1.5% |
| Target Material | Ferromagnetic steel |
| Shaft Diameter Requirement | ≥80 mm |
| Thread Type | M18 × 1.5 |
| Cable Type | PTFE insulated cable |
| Cable Length | 10 m |
| Operating Temperature | -35°C to +180°C |
| Short-Term Temperature | Up to +200°C |
| Compatible Converter | CON021 / CON031 |
| Protection Rating | IP66 |
| Dimensions | Approx. 16 mm diameter |
| Weight | Approx. 0.2 kg |
| Application Areas | Steam turbines, gas turbines, hydro turbines, compressors, pumps, fans, gearboxes, and rotating machinery monitoring systems |
FAQ
Q1: What is the main function of the PR6424/000-121?
A1: The PR6424/000-121 is an eddy current displacement sensor used for non-contact monitoring of shaft displacement, vibration, axial position, eccentricity, and speed in critical rotating equipment.
Q2: What type of sensor is the PR6424/000-121?
A2: It is a 16 mm eddy current probe designed for large rotating machinery condition monitoring applications.
Q3: What is the measuring range of the PR6424/000-121?
A3: The sensor provides a 4 mm measuring range with a sensitivity of 4 V/mm.
Q4: Which converter is used with the PR6424/000-121?
A4: The sensor can be used with EPRO signal converters such as CON021 or CON031 depending on system requirements.
Q5: What machines are suitable for the PR6424/000-121?
A5: It is commonly used in steam turbines, gas turbines, hydro turbines, compressors, pumps, fans, and other rotating machinery.
Q6: What is the operating temperature range of the PR6424/000-121?
A6: The sensor operates from -35°C to +180°C, with short-term temperature capability up to +200°C.
Q7: What cable length does the PR6424/000-121 use?
A7: This model is configured with a 10 m cable suitable for large equipment installation requirements.
Q8: What should be checked if the sensor signal is unstable?
A8: Check the probe installation gap, cable connection, converter compatibility, power supply, grounding, shaft material, and signal wiring condition.
Epro PR6424/000-121 Eddy Current Displacement Sensor is in stock. Please contact us for a quick quote and competitive pricing.
