Foxboro FBM223 PROFIBUS-DP Communication Interface Module – I/A Series
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Foxboro |
| Product Type | PROFIBUS-DP Communication Interface Module |
| Product Model | FBM223 |
| Product Series | I/A Series |
| Primary Function | PROFIBUS-DP fieldbus communication |
| Communication Interface | 2 isolated PROFIBUS-DP channels |
| Internal Fieldbus | Redundant 2 Mbps module Fieldbus |
| Physical Interface | EIA RS-485 |
| PROFIBUS-DP Data Rate | Selectable from 9.6 kbit/s to 12 Mbit/s |
| Bus Segment | Up to 32 active devices per segment according to PROFIBUS-DP requirements |
| Maximum Devices per Port | Up to 91 supported devices |
| Channel Isolation | Galvanically isolated |
| Power Supply | 24 VDC (+5% / −10%), redundant |
| Maximum Power Consumption | 6 W |
| Mounting | Modular Baseplate; DIN rail or 19-inch rack mounting via baseplate |
| Operating Temperature | −20 to +70°C |
| Relative Humidity | 5–95%, non-condensing |
| Dimensions (L × W × H) | 104 × 45 × 102 mm; 114 mm including mounting lugs |
| Weight | Approx. 284 g |
| Typical Module Part Number | P0917HD |
| Battery | No |
| Magnet | No |
FAQ
Q: What is the Foxboro FBM223 used for?
A: The FBM223 is a PROFIBUS-DP communication interface module used to connect PROFIBUS-DP field devices with a Foxboro I/A Series control system.
Q: How many PROFIBUS-DP channels does the FBM223 have?
A: It provides two communication channels, with each channel interfacing to an isolated PROFIBUS-DP bus.
Q: What communication protocol does the FBM223 support?
A: The module is designed for PROFIBUS-DP communication and conforms to the relevant PROFIBUS fieldbus and EIA RS-485 requirements.
Q: What is the communication speed of the FBM223?
A: The PROFIBUS-DP data rate is selectable from 9.6 kbit/s up to 12 Mbit/s, allowing the module to accommodate different fieldbus network configurations.
Q: Does the FBM223 provide galvanic isolation?
A: Yes. The two PROFIBUS-DP communication channels are galvanically isolated, helping reduce ground-loop and electrical interference issues between network segments.
Q: What power supply does the FBM223 require?
A: The module uses a redundant 24 VDC supply with an allowable range of +5% to −10%. Maximum power consumption is approximately 6 W.
Q: What are the dimensions and weight of the FBM223?
A: The module is approximately 104 × 45 × 102 mm (L × W × H) and weighs about 284 g. Including the mounting lugs, the overall height is approximately 114 mm.
Q: Does the FBM223 contain a battery or magnet?
A: No. The FBM223 does not contain a battery or permanent magnet. It is an electronic PROFIBUS-DP communication module.
Foxboro FBM223 PROFIBUS-DP Communication Interface Module – I/A Series is in stock. Please contact us for a quick quote and competitive pricing.
