GE Fanuc HE693ADC816D Analog Input Module
Product Overview
The GE Fanuc HE693ADC816D Analog Input Module is a high-density, 16-channel analog input unit designed for use with the GE Fanuc Series 90-30 PLC platform. Engineered to provide accurate conversion of analog signals into digital values, this module supports voltage and current input ranges, enabling precise data acquisition from field instrumentation such as sensors and transmitters. With a compact design and robust electrical isolation, it ensures reliable and interference-free operation in demanding industrial automation and process control environments.
Key Features
-
High-Density Analog Input: Supports 16 single-ended analog input channels for efficient signal acquisition in space-constrained installations.
-
Multiple Signal Types: Accepts both 0–10 V voltage inputs and 4–20 mA current loop signals, making it adaptable to various sensor outputs.
-
High Resolution: Offers 12-bit resolution for accurate signal digitization and enhanced control precision.
-
Electrical Isolation: Channel-to-backplane isolation protects the system against electrical disturbances and improves measurement integrity.
-
Status Indicators: Built-in LEDs provide status feedback for module power and faults, simplifying diagnostics and maintenance.
-
Compact and Scalable: Easily fits into GE Fanuc Series 90-30 racks, supporting system expansion and modular architecture.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 34 x 145 x 140 mm |
| Weight | 0.5 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | HE693ADC816D |
| Module Type | Analog Input Module |
| Number of Channels | 16 single-ended |
| Input Signal Type | 0–10 V DC or 4–20 mA current |
| Mounting | GE Fanuc Series 90-30 rack |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Resolution | 12-bit |
| Input Impedance | >100 kΩ (voltage), 250 Ω (current) |
| Isolation | 1500 V RMS channel-to-backplane |
| Power Consumption | < 6 W |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | GE Fanuc Series 90-30 |
| Communication Interface | Backplane communication |
| Software Configuration | Logicmaster 90 / Proficy Machine Edition |
Industry Applications
-
Process Automation: Provides analog data acquisition for temperature, level, flow, and pressure monitoring in industries such as chemical, petrochemical, and pharmaceutical.
-
Factory Automation: Supports precision measurement in automated assembly lines and quality monitoring systems.
-
Energy and Utilities: Enables integration with monitoring systems in power generation and distribution facilities.
-
Water and Wastewater: Acquires sensor data for flow, turbidity, and chemical dosing control in treatment plants.
-
HVAC and Building Control: Interfaces with analog environmental sensors for efficient energy and climate management.
The GE Fanuc HE693ADC816D Analog Input Module is a versatile and reliable component for industrial control systems, offering high-density analog signal processing with the performance and flexibility required for modern automation challenges.
