GE Fanuc IC200ALG265 Analog Input Modules
__________________________________________________________________________________________
Product Overview
The GE Fanuc IC200ALG265 Analog Input Module is designed for use with GE Fanuc’s Series 90-30 programmable logic controllers (PLCs). This module provides 16 channels for analog input signals and is optimized for both standard and process control applications. With high precision and reliability, it is suitable for environments where accurate analog measurements are crucial. The IC200ALG265 is designed to interface seamlessly with other components in industrial automation systems, ensuring smooth data acquisition and integration.
Key Features
-
16 Channels of Analog Input: Provides up to 16 channels for inputting various analog signals such as voltage or current.
-
High Accuracy and Resolution: Offers precise signal conversion with high resolution, ensuring accurate readings in industrial applications.
-
Flexible Input Range: Supports various input types including 0-10V, 4-20mA, and others, providing flexibility for different field devices and sensors.
-
Compatibility: Fully compatible with GE Fanuc Series 90-30 PLC systems for seamless integration.
-
Built-in Diagnostics: Equipped with diagnostics LEDs to indicate module status and potential issues, simplifying troubleshooting.
-
Compact Design: Space-efficient design suitable for installation in standard PLC racks, minimizing footprint in control panels.
-
Isolation: Provides electrical isolation between input channels to protect against voltage spikes and electrical noise.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 82.55 x 155 x 51 mm |
| Weight | 1.36 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | IC200ALG265 |
| Module Type | Analog Input Module |
| Number of Inputs | 16 channels |
| Input Type | Voltage, Current (0-10V, 4-20mA, etc.) |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Input Voltage Range | 0-10 V DC or 4-20 mA |
| Input Impedance | > 10 MΩ (voltage input) |
| Power Consumption | < 2 W |
| Operating Temp | -25°C to +70°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | GE Fanuc Series 90-30 PLC |
| Communication Interface | Series 90-30 backplane |
| Software Configuration | GE Fanuc Logicmaster or CIMPLICITY |
Industry Applications
-
Manufacturing Automation: Provides accurate analog inputs for various sensors and devices used in industrial automation, such as temperature, pressure, and flow meters.
-
Process Control: Used in process industries for continuous monitoring of analog signals from critical process devices, ensuring stable operations.
-
Energy Management: Integrates with energy monitoring systems to capture analog signals from power meters, enhancing energy efficiency.
-
Machine Control: Suitable for applications requiring precise control of machine operations based on analog input data.
-
Building Automation: Used in HVAC, lighting, and security systems to monitor environmental conditions and control energy usage.
The GE Fanuc IC200ALG265 Analog Input Module is a versatile and high-performance solution for analog signal acquisition in industrial environments. Its accuracy, reliability, and compatibility with GE Fanuc’s Series 90-30 PLC make it a crucial component for seamless system integration in various industrial applications.
