GE Fanuc IC200CPU005-EF CPU Module
Product Overview
The GE Fanuc IC200CPU005-EF CPU Module is a central processing unit designed for use in the GE Fanuc Series 90-30 programmable logic controllers (PLCs). This module provides the processing power and memory necessary to execute logic programs and control systems within a variety of industrial applications. It is designed to support modular expansion, enabling integration with various I/O modules and communication devices for scalable automation solutions. With its robust performance and flexibility, the IC200CPU005-EF is an ideal choice for process control, factory automation, and data acquisition systems.
Key Features
-
Powerful Processing Performance: Equipped with a high-speed processor that executes logic, control, and communication tasks efficiently.
-
Large Memory Capacity: Provides ample memory for storing large programs and data, enabling the handling of complex automation tasks.
-
Modular Design: Easily integrates with a wide range of I/O modules, communication modules, and other expansion units for flexible system configuration.
-
Reliable Operation: Designed for industrial environments, offering high reliability and uptime in continuous operation.
-
Advanced Diagnostics: Built-in diagnostic LEDs and fault detection mechanisms for real-time system monitoring and troubleshooting.
-
Support for Multiple Communication Protocols: Compatible with various GE Fanuc communication protocols for seamless connectivity with other devices.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 89 x 114 x 38 mm |
| Weight | 0.181 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | IC200CPU005-EF |
| Module Type | CPU Module |
| Processor | 32-bit processor |
| Memory | 8 MB SRAM, 2 MB Flash |
| Communication | Built-in serial, supports additional communication modules |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 5 V DC ± 5% |
| Power Consumption | < 5 W |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | GE Fanuc Series 90-30 PLC |
| Communication Interface | Serial, Ethernet, Modbus, and more |
| Software Configuration | GE Fanuc Logicmaster, CIMPLICITY, or Proficy iFix |
Industry Applications
-
Manufacturing Automation: Acts as the brain of production lines, controlling machinery and coordinating I/O devices for efficient manufacturing processes.
-
Process Control: Used in industries like chemical, oil, and gas for controlling complex processes such as batch processing and continuous flow systems.
-
Building Automation: Controls HVAC, lighting, and security systems in commercial and industrial buildings, enhancing operational efficiency.
-
Energy Management: Used in power plants and energy grids for monitoring and controlling energy generation and distribution systems.
-
Water Treatment: Controls pumps, valves, and sensors in water treatment facilities for effective monitoring and treatment processes.
The GE Fanuc IC200CPU005-EF CPU Module is an essential component of the Series 90-30 PLC system. Its powerful processing capability, extensive memory, and support for various communication protocols make it a versatile solution for industrial automation and control systems. Whether used in manufacturing, process control, or energy management, it provides a reliable and scalable solution for complex automation tasks.
