GE Fanuc IC200UAL006-CC VersaMax Microcontroller Processor
Product Overview
The GE Fanuc IC200UAL006-CC is a VersaMax Microcontroller Processor designed to deliver compact, cost-effective, and reliable control for small to mid-sized industrial automation systems. It integrates CPU, I/O, and power supply functions in a single, space-saving unit. Part of the GE VersaMax family, this all-in-one controller supports a range of discrete and analog control functions, communication protocols, and user-friendly configuration via programming tools such as Proficy Machine Edition (PME). It is ideal for applications in OEM equipment, machine control, and distributed automation networks.
Key Features
-
Integrated CPU, I/O, and Power Supply – Reduces wiring, footprint, and system complexity
-
32 Built-In I/O Points – Includes 20 digital inputs and 12 digital outputs (relay type)
-
User Memory – 14 KB of user program memory for flexible logic applications
-
High-Speed Counters – Supports fast input processing for real-time applications
-
Communication Port – Equipped with RS-232/RS-485 serial port for device integration
-
DIN Rail Mountable – Compact, modular form factor suitable for tight control panels
-
Proficy Machine Edition Support – Enables intuitive configuration and diagnostics
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 90 x 150 x 100 mm |
| Weight | 0.762 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Power Supply | 24 VDC nominal (internal power supply) |
| Digital Inputs | 20 points, 24 VDC sink/source type |
| Digital Outputs | 12 points, relay type (2.0 A max/channel) |
| Input Current | < 7 mA per input |
| Output Rating | 2 A per output (resistive load) |
| Isolation | Field-to-logic isolation via opto-couplers |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | 0°C to +55°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Protection | IP20 (when installed in panel) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Programming Software | Proficy Machine Edition (Logic Developer) |
| Communication Ports | RS-232/RS-485 combo serial port |
| Mounting | DIN rail or panel mountable |
| Expansion Support | Compatible with VersaMax expansion modules |
| Memory | 14 KB user program memory, 8 KB user data memory |
Industry Applications
-
Machine Building – Ideal for packaging machines, conveyor control, and small machinery
-
Material Handling – Manages sortation, loading, and transfer systems
-
Water & Wastewater – Compact control for pumps, valves, and level monitoring
-
HVAC & Building Automation – Efficient operation of fans, dampers, and sensors
-
Food & Beverage – Localized control in processing and packaging equipment
The GE Fanuc IC200UAL006-CC VersaMax Microcontroller Processor combines compact design, integrated control, and reliable operation to deliver flexible automation for a wide range of industrial applications. Its modularity and ease of use make it a strong fit for OEMs and distributed system architectures.
GE Fanuc IC200UAL006-CC VersaMax Microcontroller Processors is in stock. Please contact us for a quick quote and competitive pricing.
