GE Fanuc IC693ACC350 PLC Module
Product Overview
The GE Fanuc IC693ACC350 is an expansion backplane designed to increase the I/O capacity of the GE Series 90-30 Programmable Logic Controller (PLC) system. This 5-slot I/O baseplate allows for the addition of up to five I/O or special function modules, extending the PLC’s capability without the need for a new CPU or main baseplate. Engineered for robust industrial environments, the IC693ACC350 ensures reliable signal and power distribution between modules and supports seamless system scalability.
Key Features
-
5-Slot Expansion Backplane – Provides space for five additional I/O or specialty modules
-
System Scalability – Enables expansion of Series 90-30 PLCs to accommodate larger applications
-
High Reliability – Designed for dependable operation in industrial environments
-
DIN-Rail or Panel Mountable – Flexible installation options in control panels or enclosures
-
Easy Integration – Connects to the main PLC baseplate using a Series 90-30 expansion cable
-
Passive Design – No active components for enhanced durability and minimal maintenance
-
Status Indicators – Includes power and communication LED indicators for quick diagnostics
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 160 x 200 x 50 mm |
| Weight | 0.5 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Backplane Slots | 5 module slots |
| Power Supply | Supplied from main or remote baseplate |
| Communication | Uses expansion cable (IC693CBL3xx series) |
| LED Indicators | Power and I/O bus status |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Vibration | IEC 60068-2 compliant |
| Protection | IP20 (when mounted) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | GE Fanuc Series 90-30 PLC |
| Compatible Modules | All Series 90-30 I/O and specialty modules |
| Expansion Method | Series 90-30 Expansion Cable |
Industry Applications
-
Manufacturing Automation – Expands I/O capacity in assembly lines and material handling systems
-
Water and Wastewater – Supports additional instrumentation and process control points
-
Energy and Utilities – Integrates with distributed control in power generation and substations
-
Oil and Gas – Enables extended process monitoring in refining and upstream operations
-
Building Management – Facilitates scalable HVAC and lighting control in large facilities
The GE Fanuc IC693ACC350 PLC Module provides a reliable and scalable means to expand Series 90-30 control systems. Its passive, durable design, combined with flexible integration options, makes it a practical solution for extending the capabilities of industrial automation systems across a wide range of applications.
