GE Fanuc IC693ALG222 Analog Input Module
Product Overview
The GE Fanuc IC693ALG222 is a 4-channel analog input module designed for the Series 90-30 PLC platform, providing accurate and reliable analog signal acquisition for industrial automation applications. It converts incoming voltage or current signals into digital values for processing by the PLC CPU. Ideal for systems requiring precise monitoring of process variables such as temperature, pressure, flow, or level, the IC693ALG222 ensures dependable performance across a wide range of industrial environments.
Key Features
-
4 Analog Input Channels – Supports multiple analog input signals for flexible data acquisition
-
Voltage and Current Input Ranges – Configurable per channel for ±10 V, 0–10 V, 4–20 mA, or 0–20 mA signals
-
High Accuracy and Resolution – 12-bit resolution provides detailed analog data for precise monitoring
-
Channel Isolation – Enhanced signal integrity with channel-to-PLC logic isolation
-
Configurable Input Types – User-configurable input ranges via programming software
-
LED Status Indicators – Visual feedback for module and channel operation
-
Compact Form Factor – Easily fits into Series 90-30 I/O racks with minimal space requirements
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 174 x 114 x 39 mm |
| Weight | 0.41 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Input Channels | 4 |
| Input Ranges | ±10 V, 0–10 V, 0–20 mA, 4–20 mA |
| Resolution | 12 bits |
| Input Impedance | Voltage: ≥10 kΩ, Current: 250 Ω |
| Accuracy | ±0.5% of full scale |
| Isolation | 1500 V RMS (field to logic) |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Vibration | IEC 60068-2 compliant |
| Protection | IP20 (when mounted) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Platform | GE Fanuc Series 90-30 PLC |
| Compatible CPUs | All Series 90-30 CPU models |
| Module Type | Analog Input |
Industry Applications
-
Process Automation – Monitors temperature, pressure, flow, and level sensors in process control systems
-
Water/Wastewater Treatment – Acquires real-time analog signals for pumping and filtration systems
-
Manufacturing – Interfaces with analog transducers in automated production environments
-
HVAC Control – Integrates analog environmental sensors for heating and cooling systems
-
Energy and Utilities – Gathers analog inputs from meters, transformers, and control systems
The GE Fanuc IC693ALG222 Analog Input Module offers precise and reliable analog data acquisition for Series 90-30 PLC systems. Its multi-range input capabilities, high resolution, and robust design make it an essential component for analog signal processing in a variety of industrial control applications.
