GE Fanuc IC693MDL760A Solenoid Valve Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693MDL760A |
| Product Series | GE Fanuc Series 90-30 |
| Product Type | Solenoid Valve Output Module |
| Output Function | Pneumatic solenoid valve control and DC output control |
| Total Output Points | 16 points |
| Pneumatic Valve Outputs | 11 points |
| 24 VDC Electrical Outputs | 5 points |
| Output Logic Type | Positive Logic |
| Solenoid Valve Type | Internal 3-way solenoid-operated valves |
| Output Voltage | 24 VDC |
| DC Output Current Rating | 0.5 A maximum per output |
| Pneumatic Supply Pressure | 0 to 100 PSI maximum |
| Output Port Function | Controls external pneumatic devices through integrated valve outputs |
| Output OFF Operation | Pneumatic outputs are vented when the corresponding output is OFF |
| External Power Requirement | Requires external 24 VDC supply for solenoid operation |
| Backplane Current Consumption | Approximately 75 mA from PLC backplane supply |
| Status Indicators | LED indicators for module and output status monitoring |
| Connection Type | Front panel pneumatic fittings and electrical terminals |
| Compatibility | GE Fanuc Series 90-30 PLC systems |
| Mounting Method | PLC rack slot installation |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimensions | Approximately 130 × 51 × 119 mm (5.12 × 2.01 × 4.69 in) |
| Weight | Approximately 0.45 kg (0.99 lb) |
| Typical Applications | Pneumatic automation systems, valve control panels, packaging equipment, and industrial machine control systems |
FAQ
Q1: What is the main function of the IC693MDL760A?
A: The IC693MDL760A is a solenoid valve output module designed for GE Fanuc Series 90-30 PLC systems. It provides direct control of pneumatic solenoid valves and 24 VDC output devices in industrial automation applications.
Q2: How many output points are available on the IC693MDL760A?
A: The module provides 16 output points, including 11 pneumatic solenoid valve outputs and 5 additional 24 VDC electrical outputs.
Q3: What type of devices can be controlled by the IC693MDL760A?
A: The module is designed to control pneumatic actuators, solenoid valves, cylinders, and other industrial devices that require 24 VDC switching control.
Q4: Does the IC693MDL760A require an external power supply?
A: Yes. An external 24 VDC power source is required to energize the solenoid outputs and provide power for connected pneumatic devices.
Q5: What is the maximum pneumatic pressure supported by the IC693MDL760A?
A: The pneumatic outputs support an external air supply pressure of up to 100 PSI maximum.
Q6: How does the module operate when an output is turned OFF?
A: When an output is switched OFF, the corresponding pneumatic channel releases pressure by venting the connected output port.
Q7: Is the IC693MDL760A compatible with all Series 90-30 PLC systems?
A: The module is designed for GE Fanuc Series 90-30 PLC platforms and can be used with compatible racks, CPUs, and system configurations.
Q8: What should be checked before replacing an IC693MDL760A module?
A: Verify PLC rack compatibility, pneumatic connections, air pressure requirements, 24 VDC supply specifications, output configuration, and application program settings before installation.
