GE Fanuc IC693MDL940J Relay Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC693MDL940J |
| Product Series | GE Fanuc Series 90-30 |
| Product Type | Relay Output Module |
| Output Function | Digital Relay Output |
| Number of Output Points | 16 points |
| Output Configuration | 4 groups of 4 relay outputs |
| Relay Contact Type | Normally Open (NO) |
| Nominal DC Voltage | 24 VDC |
| Nominal AC Voltage | 120/240 VAC |
| Output Voltage Range | 5 to 30 VDC / 5 to 250 VAC |
| Frequency Range | 50/60 Hz for AC loads |
| Maximum Load Current | 2 A per output point |
| Maximum Common Current | 4 A per output group |
| Minimum Load Current | 10 mA |
| Maximum Inrush Current | 5 A |
| Isolation Voltage | 1500 VAC between field side and logic side; 500 VAC between groups |
| Output Response Time | 15 ms maximum ON and OFF response |
| Internal Power Consumption | 7 mA from 5 VDC backplane supply; 135 mA from relay 24 VDC supply (all outputs ON) |
| Output Status Indicators | Individual LED indicators for output status monitoring |
| Protection Features | Built-in suppression circuits for AC and DC inductive loads |
| Fuse Protection | No external output fuses required |
| Mounting Method | Series 90-30 PLC baseplate installation |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Dimensions | Approximately 125 × 51 × 119 mm (4.92 × 2.01 × 4.69 in) |
| Weight | Approximately 0.40 kg (0.88 lb) |
| Typical Applications | Motor starters, solenoid valves, indicators, alarms, and industrial automation control systems |
FAQ
Q1: What is the main function of the IC693MDL940J?
A: The IC693MDL940J is a relay output module designed for GE Fanuc Series 90-30 PLC systems. It provides switching control for external AC and DC field devices in industrial automation applications.
Q2: How many output channels are available on the IC693MDL940J?
A: The module provides 16 relay output points arranged into four independent groups, with four outputs in each group.
Q3: What type of loads can the IC693MDL940J control?
A: The relay outputs can control various industrial loads, including contactors, motor starters, solenoid valves, lamps, and alarm devices within the specified electrical ratings.
Q4: What voltage range does the IC693MDL940J support?
A: The module supports 5 to 30 VDC loads and 5 to 250 VAC loads, making it suitable for a wide range of industrial switching applications.
Q5: Does the IC693MDL940J require an external power supply?
A: The module receives logic power through the PLC backplane. Field devices are powered separately according to their voltage requirements.
Q6: How does the IC693MDL940J protect relay contacts during switching?
A: The module includes suppression circuits designed for inductive loads. DC circuits use diode-based suppression, while AC circuits use resistor-capacitor suppression methods.
Q7: Can the IC693MDL940J be installed in any Series 90-30 rack slot?
A: Yes. The module can generally be installed in any available Series 90-30 baseplate slot that supports discrete I/O modules.
Q8: What should be checked when replacing an IC693MDL940J module?
A: Before replacement, verify the PLC system compatibility, output wiring configuration, load voltage requirements, current ratings, and application program settings to ensure reliable operation.**
