GE Fanuc IC694CHS392 RX3i Serial Expansion Baseplate
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
IC694CHS392
| Parameter | Specification |
|---|---|
| Product Model | IC694CHS392 |
| Product Type | RX3i Serial Expansion Baseplate (Backplane) |
| Series | GE Fanuc / Emerson PACSystems RX3i |
| Function | Provides 10-slot expansion backplane for RX3i I/O and communication modules via high-speed serial bus |
| System Role | Baseplate / rack expansion hardware (not CPU, not I/O module) |
| Application Area | Industrial automation, distributed control systems, process plants, power systems |
| Slot Capacity | 10 module slots |
| Supported Modules | I/O modules, communication modules, special function modules (RX3i family) |
| Backplane Type | High-speed serial backplane only (no PCI support) |
| Expansion Distance | Up to 50 ft (≈15 m) between racks |
| Power Consumption | ~150 mA @ 5 VDC |
| Power Supply Slot | Requires dedicated power supply module in leftmost slot |
| Power Supply Options | IC694PWR321 / IC694PWR330 / IC694PWR331 |
| Expansion Support | Supports chained expansion racks (system dependent configuration) |
| Configuration | DIP switch selectable backplane settings |
| Hot Swap Support | Not supported (modules must be installed with power off) |
| Termination | Requires termination resistor at last rack (system dependent accessory) |
| Diagnostics | Backplane communication status via CPU diagnostics |
| Mounting Type | Panel-mounted rack baseplate |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5%–95% non-condensing |
| Dimensions (approx.) | ~5.12 in × 17.44 in × 5.59 in (H × W × D) |
| Weight | ~1.0–4.0 kg (depending on configuration and accessories) |
FAQ
What is IC694CHS392 used for?
It is a 10-slot RX3i expansion baseplate used to extend a PLC rack and connect additional I/O or communication modules.
Is it a PLC or I/O module?
No. It is a backplane (rack hardware), not an active control or I/O device.
What does it do in the system?
It:
- Provides physical slots for modules
- Distributes backplane power
- Enables high-speed serial communication between modules and CPU
What is required for operation?
- A compatible power supply module in slot 0
- RX3i CPU or head rack connection
- Proper termination for expansion chain
Where is it commonly used?
It is used in GE RX3i PACSystems distributed control architectures, especially in large industrial automation and process control systems.
GE Fanuc IC694CHS392 RX3i Serial Expansion Baseplate is in stock. Please contact us for a quick quote and competitive pricing.
