GE Fanuc IC694PWR321B Standard Power Supply Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IC694PWR321B |
| Product Type | Standard Power Supply Module |
| Series Compatibility | GE Fanuc PACSystems RX3i PLC System |
| Module Function | Provides DC power conversion and distribution for RX3i CPU, I/O modules, and expansion backplanes |
| Input Voltage Rating | 120/240 VAC or 125 VDC |
| AC Input Voltage Range | 85 to 264 VAC |
| DC Input Voltage Range | 100 to 300 VDC |
| Input Frequency | 50/60 Hz |
| Maximum Input Power | 90 VA with AC input; 50 W with DC input |
| Total Output Power | 30 W maximum |
| Output Voltage | +5 VDC, Relay +24 VDC, Isolated +24 VDC |
| +5 VDC Output Capacity | 15 W maximum |
| Relay +24 VDC Output Capacity | 15 W maximum |
| Isolated +24 VDC Output Capacity | 20 W maximum |
| +24 VDC Output Current | 0.8 A maximum |
| Inrush Current | 4 A peak, 250 ms maximum |
| Output Regulation | Stable regulated DC output for PLC system operation |
| Isolation Voltage | 1500 VAC between input and backplane |
| Protection Features | Overvoltage protection, overcurrent protection, and internal fuse protection |
| Ride-Through Time | 20 ms minimum |
| Installation Method | Installed in PACSystems RX3i backplane power supply slot |
| Expansion Support | Supports RX3i expansion and remote backplane configurations |
| Status Indicators | LED indicators for power and operating status |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | Approx. 135 mm × 69 mm × 135 mm |
| Weight | Approx. 0.5 kg |
| Application Areas | Industrial automation, PLC control systems, distributed I/O networks, and process control applications |
| Reliability Features | Provides stable multi-output power conversion with protective functions for demanding industrial environments |
FAQ
Q1: What is the IC694PWR321B used for?
- The IC694PWR321B is a power supply module designed for GE Fanuc PACSystems RX3i PLC systems. It provides regulated power for CPUs, I/O modules, and expansion components.
Q2: What input voltage does the IC694PWR321B support?
- The module supports 120/240 VAC and 125 VDC input sources, allowing use in various industrial power systems.
Q3: What output voltages are available from the IC694PWR321B?
- The module provides +5 VDC output, Relay +24 VDC output, and isolated +24 VDC output for PLC modules and external control circuits.
Q4: What is the maximum output capacity of the IC694PWR321B?
- The power supply provides a maximum total output capacity of 30 W with separate capacity limits for each voltage output channel.
Q5: Does the IC694PWR321B include protection functions?
- Yes. The module includes overvoltage protection, overcurrent protection, and internal fuse protection to improve system safety and reliability.
Q6: Where is the IC694PWR321B installed?
- The module is installed in the dedicated power supply slot of a compatible PACSystems RX3i backplane.
Q7: What applications commonly use the IC694PWR321B?
- Typical applications include factory automation, machine control systems, distributed I/O systems, manufacturing equipment, and industrial process control.
Q8: What should be checked before replacing an IC694PWR321B module?
- Users should verify PLC system compatibility, input voltage specifications, power requirements, backplane configuration, wiring connections, and installation conditions before replacement.
GE Fanuc IC694PWR321B Standard Power Supply Module is in stock. Please contact us for a quick quote and competitive pricing.
