GE Fanuc IS200STCIH4A Simplex Thermocouple Input Board
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | IS200STCIH4A |
| Manufacturer | GE Industrial Systems |
| Product Family | Mark VI Turbine Control System / EX2100 Excitation System |
| Product Type | Simplex Thermocouple Input Board (Isolated) |
| Module Type | STCI Board |
| Function | Acquires, isolates, conditions, and processes thermocouple signals for temperature monitoring, control, and protection functions |
| Application | Gas Turbine Control, Steam Turbine Control, Generator Monitoring, Industrial Process Automation |
| Input Signals | Thermocouple Inputs |
| Supported Thermocouple Types | J, K, T, E, R, S, B, N |
| Input Channels | Multiple Isolated Thermocouple Channels |
| Signal Conditioning | Cold Junction Compensation (CJC), Linearization, Filtering, Isolation, Analog-to-Digital Conversion |
| Measurement Function | High-Accuracy Temperature Measurement |
| Accuracy | High Precision Industrial Temperature Monitoring |
| Communication Interface | Backplane Communication Interface |
| Isolation Type | Galvanic Isolation Between Field Inputs and Control Electronics |
| Diagnostic Features | Open Thermocouple Detection, Short-Circuit Detection, Sensor Failure Monitoring, Self-Diagnostics |
| LED Indicators | Power, Status, Channel Activity, Fault Indicators |
| Connector Type | Terminal Blocks and High-Density Backplane Connectors |
| Mounting Type | Rack-Mounted Printed Circuit Board |
| Power Supply | Backplane Powered |
| System Compatibility | GE Mark VI and EX2100 Control Systems |
| Redundancy Support | Simplex Architecture |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -30°C to +65°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Dimensions (H × W × D) | 241 × 160 × 25 mm |
| Weight | 0.45 kg |
| Typical Applications | Turbine Exhaust Temperature Monitoring, Bearing Temperature Monitoring, Generator Temperature Protection, Industrial Thermal Process Control |
| Revision Level | H4A |
| Lifecycle Status | Obsolete / Legacy Product |
FAQ
Q1: What is the IS200STCIH4A?
A1: The IS200STCIH4A is an isolated thermocouple input (STCI) board used in GE Mark VI and EX2100 systems to acquire and process thermocouple temperature signals.
Q2: What is the primary function of the module?
A2: Its primary function is to convert thermocouple signals into accurate temperature measurements while providing isolation and signal conditioning for reliable control system operation.
Q3: Which systems use the IS200STCIH4A?
A3: The board is commonly used in GE Mark VI turbine control systems and EX2100 excitation control platforms.
Q4: What thermocouple types are supported?
A4: The module supports standard industrial thermocouples including J, K, T, E, R, S, B, and N types.
Q5: What diagnostic features are available?
A5: Features include open-thermocouple detection, short-circuit detection, sensor health monitoring, self-diagnostics, and LED status indicators.
Q6: Does the module provide electrical isolation?
A6: Yes. Galvanic isolation protects the control electronics from electrical disturbances and improves measurement accuracy.
Q7: What are the typical applications?
A7: Typical applications include turbine exhaust temperature monitoring, bearing temperature monitoring, generator protection, and industrial thermal process control.
Q8: Is the IS200STCIH4A still available?
A8: The IS200STCIH4A is a legacy GE component. Refurbished, surplus, and replacement units are generally available through industrial automation suppliers.
GE Fanuc IS200STCIH4A Simplex Thermocouple Input Board is in stock. Please contact us for a quick quote and competitive pricing.
