GE Fanuc IC695ALG708-EC – RX3i Analog Output Module
The GE Fanuc IC695ALG708-EC is an advanced analog output module designed for the PACSystems RX3i series. The module provides eight configurable analog output channels with voltage and current output options. Its high accuracy, rugged design, and software-configurable parameters make it an ideal choice for industrial automation systems that require reliable analog signal control.
Technical specifications
| Specification | detail |
|---|---|
| model | IC695ALG708-EC |
| Product Type | Analog output modules |
| series | PACSystems RX3i |
| Number of output channels | 8 |
| Output signal range | – Voltage: ±10V, 0-10V – Current: 0-20mA, 4-20mA |
| solve | 12 bits |
| accuracy | ±0.15% of full scale at 25°C ±0.30% of full scale at 60°C |
| Update rate per channel | Approximately 8 ms |
| Configuration | Software configurable; individual channel enable/disable |
| Alarm detection | High, Low, High-High, Low-Low Alarms |
| Overvoltage protection | Yes |
| Power Requirements | External +24V DC power supply current consumption: 250mA (max) |
| Power consumption | 7.25 W max |
| Operating temperature range | -40°C to +70°C |
| Storage temperature range | -40°C to +85°C |
| Humidity range | 5% to 95% RH (non-condensing) |
| Dimensions (W x H x D) | 34 mm × 145 mm × 140 mm |
| weight | 0.5 kg |
| Install | Insert into RX3i Universal Backplate |
| index | LED status indicators for module status and individual channel status |
| Certification | CE marked, UL listed and CSA certified |
| isolation | Non-isolated output |
| diagnosis | Built-in self-test and diagnostic capabilities |
| Firmware Upgrade | Field upgradeable firmware via programming software |
| obey | Comply with relevant industrial automation standards |
Key Features and Benefits
1. Multiple analog output functions
The IC695ALG708-EC has eight output channels, each of which can be configured as a voltage or current output, making it suitable for a wide range of industrial applications such as actuators, control valves, and instrumentation.
2. High precision and high accuracy
With 12-bit resolution and ±0.15% accuracy at 25°C, the module ensures precise signal control for improved process performance and system efficiency.
3. Advanced alarm and protection functions
The module provides configurable alerts including high, low, high-high, and low-low thresholds. In addition, overvoltage protection prevents damage caused by excessive input voltage.
4. Software Configurable Parameters
The IC695ALG708-EC is fully configurable through software, allowing the user to adjust settings such as output range, alarms and channel activation without the need for physical jumpers or switches.
5. Sturdy industrial design
Designed for harsh industrial environments, the module can operate reliably in extreme temperatures, high humidity and harsh conditions, ensuring long-term durability.
application
GE Fanuc IC695ALG708-EC is widely used in various industrial fields, including:
- Process Automation : Control analog equipment in industries such as oil and gas, chemical processing, and water treatment.
- Manufacturing : Ensure precise analog control in automated production lines.
- Energy management : Regulating analog devices in power generation and distribution.
- Building Automation : Manages HVAC systems, lighting controls, and other analog control building management systems.
Recommended related models
| model | describe |
|---|---|
| IC695ALG704 | 4-channel analog output module |
| IC695ALG600 | 8-Channel Analog Input Module |
| IC695ALG616 | 16-Channel Analog Input Module |
| IC695ALG628 | 8-Channel RTD Input Module |
| IC695ALG626 | 8-Channel Thermocouple Input Module |
| IC695CPE305 | RX3i CPU with 1.1 GHz processor and 5 MB RAM |
| IC695CMM002 | Dual-port serial communication module |
| IC695ETM001 | Ethernet interface module |
| IC695PSD040 | 40W Power Module |
| IC695RMX128 | Redundant memory switch module |
