Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE Multilin |
| Model | UR 8LH |
| Product Type | CT/VT Module |
| Series | GE Multilin Universal Relay (UR) Series |
| Phase CT Inputs | 3 × 1 A / 5 A |
| Ground CT Input | 1 × 1 A / 5 A |
| VT Inputs | 4 |
| CT/VT Configuration | 4 CT / 4 VT |
| Diagnostic Function | Enhanced analog signal integrity diagnostics |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Isolation | 2.5 kV RMS |
| System Frequency | 50/60 Hz |
| Installation Type | Plug-in modular installation |
| Compatibility | GE Multilin Universal Relay Series |
| Dimensions | 120 × 30 × 100 mm |
| Weight | 1.2 kg |
FAQ
1. What is the GE UR 8LH CT/VT Module used for?
The GE UR 8LH is a CT/VT input module designed for GE Multilin Universal Relay systems. It receives current and voltage signals from external current transformers and voltage transformers, conditions these signals, and provides the relay with suitable measurement inputs for protection, metering, monitoring, and system diagnostics.
2. How many CT and VT inputs does the UR 8LH provide?
The UR 8LH provides a 4 CT / 4 VT configuration. The CT section consists of three phase CT inputs rated for 1 A or 5 A and one ground CT input rated for 1 A or 5 A. The module also provides four VT inputs for voltage measurement within the Universal Relay system.
3. What is the difference between the UR 8LH and a standard CT/VT module?
The UR 8LH is designed with enhanced diagnostic capabilities in addition to its normal CT/VT signal conditioning function. These diagnostics help the relay evaluate the integrity of incoming analog signals, making it easier to identify abnormal measurement conditions and improve the reliability of protection and monitoring functions.
4. Can the UR 8LH be used to replace an existing CT/VT module?
Yes, the UR 8LH can be used for replacement, system upgrades, or applications where additional CT/VT functionality is required. However, the replacement should be performed only after confirming the relay model, CPU compatibility, firmware requirements, module configuration, and wiring arrangement to avoid hardware or configuration mismatches.
5. What CT input ratings are supported by the UR 8LH?
The phase CT inputs support 1 A or 5 A secondary current signals, while the ground CT input also supports 1 A or 5 A. The CT secondary rating must match the connected transformer and the configuration of the Universal Relay. Incorrect CT ratings or wiring can cause inaccurate measurements and may affect protection performance.
6. Does the UR 8LH provide sensitive ground fault protection?
The UR 8LH is primarily a 4 CT / 4 VT module with enhanced analog signal diagnostics. It should not be treated as a dedicated sensitive-ground CT module. If an application requires a specific sensitive-ground measurement arrangement, the CT/VT module type should be selected according to the protection scheme and relay configuration.
7. How does the UR 8LH help with analog signal diagnostics?
The module continuously provides conditioned CT and VT signals to the relay, while its enhanced diagnostic functionality can assist in checking analog signal integrity. This is useful for detecting abnormal input conditions, wiring problems, or signal inconsistencies before they develop into larger protection or measurement issues.
8. What should be checked when installing or replacing a UR 8LH module?
Before installation, verify the exact module model, CT ratios, VT configuration, terminal wiring, relay compatibility, CPU requirements, and firmware compatibility. CT circuits should be handled carefully because an energized CT secondary must not be left open. After installation, the relay configuration should be checked and the CT/VT measurements verified under suitable operating or test conditions.
GE UR 8LH CT/VT Module is in stock. Please contact us for a quick quote and competitive pricing.
