HIMA F3316 Product Documentation
Product Introduction
The HIMA F3316 is a high-performance safety relay designed for industrial applications requiring reliable and fail-safe operation. It is part of HIMA’s renowned safety system portfolio, offering robust protection for machinery and processes. The F3316 is widely used in sectors such as oil & gas, chemical processing, and power generation, where safety is critical.
The relay features a modular design, allowing for easy integration into existing control systems. Its high fault tolerance and diagnostic capabilities ensure minimal downtime while maintaining compliance with international safety standards such as IEC 61508 and SIL 3.
Product Advantages
- High Reliability: Engineered for fail-safe operation, reducing the risk of undetected failures.
- Modular Design: Allows flexible configuration and easy expansion.
- Compliance with Safety Standards: Meets SIL 3 (IEC 61508) and other industry-specific certifications.
- Advanced Diagnostics: Provides real-time monitoring and fault detection.
- Durable Construction: Designed for harsh industrial environments with high resistance to electrical noise and temperature fluctuations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Dimensions | 200 ×100 × 25 mm |
| Weight | 0.3kg |
| Operating Voltage | 24V DC (Range: 18V – 30V DC) |
| Current Rating | 5A (Max) |
| Contact Type | 4 NO (Normally Open) + 2 NC (Normally Closed) |
| Operating Temperature | -20°C to +60°C |
| Protection Class | IP20 |
| Certifications | SIL 3, IEC 61508, CE, UL |
Applications
The HIMA F3316 is suitable for:
- Emergency shutdown systems (ESD)
- Fire and gas detection systems
- Burner management systems
- Railway signaling
- Industrial automation safety circuits
Compatible Models
The F3316 can be used alongside:
- HIMA F35 (Safety Controller)
- HIMA F8627 (I/O Module)
- HIMA HIMatrix (Safety PLC)
- HIMA F3 DI 8/8 (Digital Input Module)
- HIMA F3 AI 4/8 (Analog Input Module)
Installation Instructions
- Mounting: Secure the relay on a DIN rail in a control cabinet.
- Wiring: Connect power supply (24V DC) to terminals 1 (+) and 2 (-).
- Input/Output Connections: Wire sensors and actuators according to the provided diagram.
- Testing: Perform a functional test to ensure proper operation before commissioning.
- Diagnostics: Use the built-in LED indicators to verify status and troubleshoot faults.
Recommended Related Models (Same Series)
| Model | Dimensions (mm) | Weight (g) | Voltage | Current | Certifications |
|---|---|---|---|---|---|
| HIMA F3315 | 120 x 80 x 45 | 430 | 24V DC | 4A | SIL 3, IEC 61508 |
| HIMA F3317 | 120 x 80 x 45 | 460 | 24V DC | 6A | SIL 3, IEC 62061 |
| HIMA F3320 | 150 x 100 x 60 | 600 | 24V DC | 8A | SIL 3, ATEX |
| HIMA F3330 | 120 x 80 x 45 | 470 | 24V DC | 5A | SIL 3, UL |
| HIMA F3340 | 150 x 100 x 60 | 620 | 24V DC | 10A | SIL 3, IEC 61508 |
| HIMA F3350 | 120 x 80 x 45 | 480 | 24V DC | 5A | SIL 3, CE |
Popular HIMA Models (Other Series)
| Model | Dimensions (mm) | Weight (g) | Voltage | Current | Key Feature |
|---|---|---|---|---|---|
| HIMA F35 | 200 x 150 x 80 | 1200 | 24V DC | 10A | Safety PLC |
| HIMA F8627 | 100 x 70 x 40 | 350 | 24V DC | 2A | I/O Module |
| HIMA HIMatrix | 300 x 200 x 100 | 2500 | 24V DC | 15A | High-end Safety System |
| HIMA F3 DI 8/8 | 80 x 60 x 30 | 250 | 24V DC | 1A | Digital Input |
| HIMA F3 AI 4/8 | 80 x 60 x 30 | 260 | 24V DC | 1A | Analog Input |
| HIMA F2 | 150 x 100 x 60 | 800 | 24V DC | 5A | Compact Safety Relay |
| HIMA F4 | 180 x 120 x 70 | 1000 | 24V DC | 8A | Modular Safety System |
| HIMA F5 | 250 x 180 x 90 | 2000 | 24V DC | 20A | High-Current Relay |
FAQ (Frequently Asked Questions)
Q1: What is the maximum load current for the HIMA F3316?
A1: The maximum load current is 5A.
Q2: Can the F3316 be used in explosive atmospheres?
A2: No, it is rated IP20 and is not suitable for explosive environments unless housed in an appropriate enclosure.
Q3: What certifications does the F3316 hold?
A3: It is certified to SIL 3 (IEC 61508), CE, and UL standards.
Q4: How do I troubleshoot a fault indicated by the LED?
A4: Refer to the manual for LED status codes. Common issues include wiring errors or supply voltage fluctuations.
Q5: Is the F3316 compatible with HIMA’s HIMatrix system?
A5: Yes, it can be integrated as part of a larger HIMatrix safety solution.
Q6: What is the expected lifespan of the F3316?
A6: Under normal operating conditions, the relay has a lifespan of over 10 years.
