Product Overview
The HIMA F3330 is a digital input module designed for use within the HIMA HIMax and HIQuad safety-related automation systems. It provides reliable and isolated acquisition of discrete input signals from field devices in safety-critical process and factory automation applications.
The F3330 is used primarily to interface digital field signals—such as limit switches, push buttons, pressure contacts, or other binary sensors—into a HIMA safety controller. The module converts incoming signals into logic-level data for processing by the system’s CPU while maintaining full electrical isolation and diagnostic capability to ensure functional safety in accordance with IEC 61508 up to SIL 3.
With advanced diagnostics, hot-swap capability, and galvanic isolation between field and system sides, the F3330 ensures maximum availability and ease of maintenance for safety instrumented systems (SIS) in industries such as oil and gas, petrochemical, power generation, and manufacturing automation.
Key Features
-
16 digital input channels with independent signal processing.
-
Galvanic isolation between input and system circuits.
-
Diagnostic functions for short circuit, line break, and signal status.
-
Hot-swap support allowing replacement during system operation.
-
Meets IEC 61508 SIL 3 safety integrity requirements.
-
Wide operating temperature range for harsh industrial environments.
-
LED indicators for input and fault status.
-
Compact design compatible with standard HIMA system racks.
Technical Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model | F3330 | Digital Input Module |
| Manufacturer | HIMA Paul Hildebrandt GmbH | Safety automation specialist (Germany) |
| System Compatibility | HIMax / HIQuad Systems | For safety-related control applications |
| Number of Channels | 16 inputs | Individually isolated and monitored |
| Input Type | Digital (24 V DC nominal) | Compatible with field contact devices |
| Input Voltage Range | 15 V DC to 32 V DC | Rated for standard industrial 24 V DC systems |
| Input Current | Approx. 6 mA per channel at 24 V DC | Typical operating current |
| Channel Isolation | 1,500 V AC galvanic isolation | Field to system isolation |
| Response Time | < 10 ms typical | Fast input update rate |
| Diagnostics | Line break, short circuit, stuck signal | Status indication via LEDs |
| LED Indicators | 16 channel LEDs + 1 module status LED | Visual input and fault display |
| Hot-Swap Capability | Supported | Can be replaced without system shutdown |
| Safety Integrity Level | Up to SIL 3 (IEC 61508) | Certified for safety-critical applications |
| Operating Temperature | −20 °C to +60 °C | Suitable for industrial environments |
| Storage Temperature | −40 °C to +85 °C | Long-term safe storage range |
| Humidity | 10% – 95% non-condensing | For control room and cabinet use |
| Power Consumption | Approx. 4 W | Typical at 24 V DC |
| Dimensions (H × W × D) | 160 mm × 50 mm × 125 mm | Compact module format |
| Weight | Approx. 0.35 kg (0.77 lb) | Lightweight construction |
| Mounting Type | Plug-in to backplane | Standard HIMA rack mounting |
| Cooling | Convection (no fan required) | Passive cooling design |
| Housing Material | Industrial-grade plastic | Flame-retardant enclosure |
| Country of Origin | Germany | Manufactured by HIMA, Brühl, Germany |
HIMA F3330 Digital Input Module is in stock. Please contact us for a quick quote and competitive pricing.
