HIMA F3417A 4-channel Relay Amplifier Module (Planar F System)

Product Overview

The HIMA F3417A 4-channel Relay Amplifier Module is a high-performance, safety-critical component designed for use in the Planar F system. It provides four independent relay outputs, each capable of handling a wide range of industrial control applications, particularly where reliable safety functions and process control are required. The module is ideal for safety-critical systems, offering high reliability, excellent diagnostics, and a compact design.

The F3417A is part of HIMA’s functional safety systems, specifically designed to meet the requirements of the IEC 61508 and ISO 13849 standards. It supports fail-safe operation and is built to withstand harsh industrial environments, providing efficient performance in mission-critical applications such as process control, safety systems, and automated machinery.

Key Features

• 4 Relay Outputs: Four independent channels allow control over multiple devices in a single module, enhancing system flexibility.

• High Reliability: Designed for demanding safety-critical applications, ensuring continuous and fail-safe operation.

• Electrical Isolation: Provides electrical isolation between the module and the connected devices, ensuring safe operation and protection of control systems.

• Compact Design: Space-efficient and easy to integrate within tight control panels and cabinets.

• Fail-Safe Operation: Ensures that in the event of a failure, the system defaults to a safe state, preventing hazardous situations.

• Real-Time Diagnostics: Features diagnostics LEDs for each output channel to indicate real-time operational status and fault conditions, allowing for easy monitoring and troubleshooting.

• Industry-Specific Certifications: Meets IEC 61508 and ISO 13849 standards for functional safety, ensuring compliance with industrial safety regulations.

Technical Specifications

3.1 Dimensions and Weight

3.2 Electrical Characteristics

3.3 Environmental Characteristics

3.4 System Compatibility

Industry Applications

• Process Control Systems: Used in process industries where safety and reliability are critical for controlling machinery and actuators.

• Safety Instrumented Systems (SIS): Ideal for implementation in safety-critical applications, ensuring fail-safe control of vital processes.

• Automation Systems: Controls the operation of equipment such as valves, relays, and motors in automated systems, particularly where redundancy and reliability are required.

• Energy and Utilities: Ensures safe and efficient control of power plants, turbines, and other critical infrastructure.

• Chemical and Pharmaceutical Industries: Used for monitoring and controlling hazardous processes, reducing the risk of accidents and ensuring compliance with industry regulations.

The HIMA F3417A 4-channel Relay Amplifier Module offers a robust and fail-safe solution for controlling safety-critical applications in the Planar F system. With its high-reliability design, real-time diagnostics, and compliance with international safety standards, the module provides an essential safety component for industrial automation and process control systems. Its compact design and ease of integration make it a versatile choice for a wide range of industries, including energy, manufacturing, and chemical processing, where functional safety and operational continuity are paramount.
