Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | HIMA |
| Model | H51Q-HRS B5233-2 |
| Ordering Number | 997205233 |
| Product Type | System Assembly Rack |
| System | H51q-HRS |
| Assembly Type | Central System Rack Assembly |
| Rack Type | K 1412A central rack |
| Rack Format | 19-inch |
| Rack Height | 5U |
| System Architecture | Redundant central modules and redundant bus architecture |
| Safety Level | Up to SIL 3 according to IEC 61508 |
| Central Processor Configuration | 2 × F 8650 central modules |
| Power Supply Configuration | 3 × F 7126 power supply modules |
| Power Supply Monitoring | F 7131 power supply monitoring module |
| Bus Termination | 4 × F 7546 bus termination modules for B5233-2 |
| Fan Configuration | 3 fan modules with fan monitoring |
| I/O Bus | Integrated I/O bus connection |
| Communication Expansion | Supports optional communication modules |
| Coprocessor Expansion | Supports optional coprocessor modules |
| Main Function | Provides the central mechanical, power and bus infrastructure for the H51q-HRS safety system |
| Typical Applications | Safety Instrumented Systems, Emergency Shutdown, Fire & Gas and critical process control |
| Mounting | Standard 19-inch industrial control cabinet |
| Dimensions | 350 × 248 × 222 mm |
| Weight | 1.8 kg |
FAQ
1. What is the main function of the HIMA H51Q-HRS B5233-2?
The H51Q-HRS B5233-2 is a central system assembly rack for the HIMA H51q-HRS safety system. It provides the mechanical structure, backplane, power distribution and bus connections required for the central system modules. The assembly is designed to accommodate redundant central processing and power-supply components within one organized rack architecture.
2. What is the relationship between H51Q-HRS B5233-2 and ordering number 997205233?
H51Q-HRS B5233-2 identifies the system assembly rack configuration, while 997205233 is the corresponding HIMA ordering number. When purchasing, replacing or checking compatibility, both identifiers should be used to ensure that the correct H51q-HRS rack assembly is selected.
3. What is the difference between B5233-1 and B5233-2?
B5233-1 is associated with the H51q-HS configuration, while B5233-2 is used for the H51q-HRS configuration. The B5233-2 version provides a redundant bus architecture together with redundant central modules, making its internal configuration different from the single-channel bus arrangement of B5233-1.
4. Which central modules are used in the B5233-2 assembly?
The B5233-2 assembly includes two F 8650 central modules in the standard configuration. These central modules form the redundant processing section of the H51q-HRS system. Additional communication and coprocessor modules can be installed when required by the specific system configuration.
5. How is power redundancy implemented in the H51Q-HRS B5233-2?
The assembly uses three F 7126 power supply modules. Their 5 V outputs are connected in parallel so that the system can maintain operation with an appropriate redundant power configuration. An F 7131 power supply monitoring module supervises the power-supply condition and supports system-level diagnostics.
6. What role does the redundant bus play in the B5233-2 system?
The redundant bus provides an additional communication path within the H51q-HRS architecture. This arrangement helps maintain system communication when a fault occurs in one bus path. It is an important part of the high-availability design used for safety-related control applications.
7. What should be checked if modules installed in the B5233-2 rack are not communicating correctly?
First check the rack power supplies, module seating and backplane connections. The status of the F 7131 power monitoring module and the relevant system diagnostics should then be reviewed. Bus termination modules and redundant bus connections should also be checked for loose connections or incorrect configuration. If the fault persists, the affected module and rack configuration should be tested according to the HIMA system maintenance procedure.
8. Where is the HIMA H51Q-HRS B5233-2 typically used?
The B5233-2 is designed for high-availability HIMA safety-control applications. Typical installations include Safety Instrumented Systems (SIS), Emergency Shutdown (ESD), Fire and Gas (F&G), process safety and other critical industrial automation applications where redundant processing, power supply and communication infrastructure are required.
