Honeywell 05701-A-0326 Field Interface Card
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Honeywell |
| Model | 05701-A-0326 |
| Product Type | Field Interface Card |
| Product Series | System 57 / 5701 |
| Main Function | Field signal interface between the sensor and single-channel control card |
| Compatible System | Honeywell System 57 / 5701 |
| Application | Fixed gas detection and industrial safety monitoring |
| Installation | Designed for installation in a System 57 / 5701 card slot |
| Relay | No built-in relay |
| Configuration | Intended for non-master channels in systems using master relays |
| Sensor Interfaces | S, 01, NS |
| Analog Output | Analogue O/P + and Analogue O/P − |
| Remote Inhibit | Supported |
| Remote Reset | Supported |
| Power Interface | +24 V and 0 V Out/In |
| Ground | Ground terminals provided |
| Terminal Range | Terminals 25–36 |
| Typical Applications | Combustible gas, toxic gas and industrial gas detection systems |
| Replacement Use | Replacement field interface card for compatible System 57 installations |
| Dimensions | 160 × 30 × 130 mm |
| Weight | 0.23 kg |
FAQ
1. What is the function of the Honeywell 05701-A-0326 Field Interface Card?
The 05701-A-0326 provides the field-level interface between a gas detection sensor and a compatible Honeywell System 57 single-channel control card. It manages the required field connections for sensor signals, analogue output, remote control functions and power.
2. Does the 05701-A-0326 have built-in alarm relays?
No. The 05701-A-0326 is a field interface card without built-in relays. It is designed for systems where relay functions are handled elsewhere, particularly on channels associated with a master relay arrangement.
3. Which Honeywell systems are compatible with the 05701-A-0326?
The card is designed for Honeywell System 57 / 5701 gas detection systems. Before replacement, the installed control card, system configuration and channel arrangement should be checked to ensure compatibility.
4. What sensor connections are available on the 05701-A-0326?
The card provides sensor-related connections identified as S, 01 and NS. These terminals are used to connect the field sensor to the associated control-card circuitry.
5. Does the 05701-A-0326 support remote inhibit and reset functions?
Yes. Dedicated terminals are provided for Remote Inhibit and Remote Reset. These connections allow external control equipment to interact with the gas detection channel when the overall system configuration supports these functions.
6. What should be checked if a sensor connected through the 05701-A-0326 is not detected correctly?
First inspect the card seating and terminal connections. Check the sensor wiring, power connections, signal terminals and cable continuity. If the wiring is correct, check the associated System 57 control card and configuration before replacing the field interface card.
7. Can the 05701-A-0326 be used as a direct replacement card?
It can be used as a replacement where the existing installation specifically requires the 05701-A-0326. The replacement should match the original System 57 configuration, channel type and wiring arrangement. After installation, the gas detection channel should be tested and recalibrated as required.
8. What are the main signs of a faulty 05701-A-0326?
Typical symptoms can include loss of sensor signal, incorrect analogue output, communication or signal abnormalities between the field sensor and control card, or failure of remote inhibit/reset functions. Troubleshooting should begin with wiring and terminal checks before replacing the card.
