Honeywell 8C-TCNT01 51307032-175 C300 Controller I/O Termination Assembly (IOTA)
Product Overview
The Honeywell 8C-TCNT01 51307032-175 is an I/O Termination Assembly (IOTA) designed for use with the C300 Controller in Honeywell’s Experion Process Knowledge System (PKS). It provides the essential interface for connecting field wiring to the controller’s I/O modules. This IOTA plays a crucial role in simplifying installation, enhancing maintainability, and improving system reliability by facilitating seamless signal routing between field devices and the controller. Its robust build and modular design ensure long-term performance in mission-critical industrial control environments.
Key Features
-
Seamless Integration: Designed for direct integration with Honeywell’s C300 controller and associated I/O modules.
-
Simplified Wiring: Provides a streamlined interface for field device wiring, minimizing complexity and reducing installation time.
-
Reliable Signal Transmission: Ensures accurate and stable signal flow between the process field and controller.
-
Modular Design: Supports quick replacement and upgrades, enhancing system flexibility and uptime.
-
Robust Construction: Built to perform in industrial environments with resistance to electrical noise, temperature variations, and vibration.
-
Maintenance-Friendly: Features clearly labeled terminals and accessible layout for efficient diagnostics and service.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 220 x 120 mm |
| Weight | 0.6 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | 8C-TCNT01 |
| Part Number | 51307032-175 |
| Module Type | I/O Termination Assembly (IOTA) |
| System | Honeywell Experion PKS |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Power Supply | Supplied via C300 backplane |
| Signal Interface | I/O signal routing and termination |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 (suitable for enclosed panels) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible Systems | Honeywell C300 Controller, Experion PKS |
| Interface Type | Termination interface for I/O modules |
| Configuration Tools | Honeywell Control Builder |
Industry Applications
-
Oil & Gas: Facilitates reliable field device connectivity in upstream and downstream control systems.
-
Power Generation: Used in turbine, generator, and auxiliary system control schemes.
-
Chemical Processing: Connects instrumentation and actuators to ensure accurate process control.
-
Pharmaceutical Manufacturing: Supports regulatory-compliant control systems with reliable I/O connections.
-
Water and Wastewater Treatment: Ensures seamless signal routing for pumps, valves, and monitoring systems.
-
Food and Beverage: Connects diverse field devices in automated production and packaging lines.
The Honeywell 8C-TCNT01 51307032-175 I/O Termination Assembly is a key component in achieving robust and reliable signal management in Honeywell’s C300 control environment. With its compact design, seamless integration, and industrial-grade durability, it is an ideal solution for critical I/O interface needs in a wide range of process automation applications.
