Honeywell 8C-TDILA1 51307141-175 Digital Input Module
Product Overview
The Honeywell 8C-TDILA1 51307141-175 Digital Input Module is designed to provide precise and reliable processing of discrete digital signals in industrial control and automation systems. It is part of the Honeywell TDC 3000 control platform and is ideal for applications where digital inputs from field devices such as switches, sensors, and relays need to be processed and transmitted to the control system. The module offers high flexibility, durability, and seamless integration with Honeywell’s advanced control systems, ensuring optimal performance in demanding industrial environments.
Key Features
-
Discrete Signal Processing: Capable of processing a wide range of digital input signals from various field devices such as limit switches, position sensors, and safety interlocks.
-
High Reliability: Built to operate reliably in harsh industrial environments, ensuring stable performance over long periods of time.
-
Wide Input Voltage Range: Supports a broad range of input voltage levels, allowing for easy integration with different field devices and equipment.
-
Optical Isolation: Each input channel is optically isolated to protect the module and other control systems from electrical noise, voltage spikes, and other disturbances.
-
Compact and Efficient Design: Designed for efficient use of space in control racks, the module’s compact form factor simplifies installation and system expansion.
-
Built-in Diagnostics: Equipped with onboard diagnostic LEDs to monitor the status of each input channel, facilitating quick troubleshooting and system maintenance.
-
Seamless Integration: Fully compatible with Honeywell’s TDC 3000 control system, providing smooth communication between the module and other system components.
-
Robust Construction: Constructed with industrial-grade materials to ensure long-lasting performance and protection in demanding environments.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 51 x 267 x 178 mm |
| Weight | 0.5 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | 8C-TDILA1 |
| Module Type | Digital Input Module |
| Number of Channels | 8 Channels |
| Mounting | Standard Honeywell control rack |
| Material | Industrial-grade metal and plastic |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Input Type | Digital (Discrete) |
| Input Voltage | 24 V DC |
| Input Current | 5 mA per channel (typical) |
| Power Consumption | < 5 W |
| Operating Temp | -20°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | Honeywell TDC 3000 |
| Communication Interface | Direct I/O bus connection |
| Software Configuration | Honeywell TDC 3000 configuration tools |
Industry Applications
-
Industrial Automation: Used to monitor and control discrete field devices such as relays, limit switches, and position sensors in manufacturing processes, ensuring accurate process control.
-
Power Generation: Supports the control of auxiliary systems and safety interlocks in power plants, helping maintain operational efficiency and safety.
-
Oil & Gas: Used in exploration, refining, and production systems to process signals from field devices like flow switches, pressure sensors, and emergency shutdown systems.
-
Chemical Processing: Provides digital input control for monitoring alarms, interlocks, and other safety-critical devices in chemical plants.
-
Water Treatment: Captures and processes input from control devices such as flow meters, level sensors, and pressure switches, ensuring proper operation of water treatment plants.
-
Building Automation: Integrates with building management systems to handle digital inputs from security systems, fire alarms, and other building control devices.
The Honeywell 8C-TDILA1 51307141-175 Digital Input Module provides an efficient and reliable solution for handling digital signals in industrial control systems. Its rugged design, ease of integration with Honeywell’s TDC 3000 control system, and built-in diagnostic features make it an essential component for process control and automation across various industries.
