Honeywell CC-GAIC21 Analog Input Module

Product Overview
The Honeywell CC-GAIC21 Analog Input Module (Part Number 51306356-175) is designed to provide high-precision analog input control for Honeywell industrial control systems. This module is capable of converting analog signals from field devices such as temperature sensors, pressure transmitters, and flow meters into digital signals for processing and control. The CC-GAIC21 is ideal for industries that require high accuracy and reliability in data acquisition, including process control, automation, and safety monitoring.

Key Features

• Multiple Analog Input Channels – Supports multiple input channels for simultaneous monitoring of various field devices, enhancing system flexibility and control

• Wide Input Range – Accepts a wide range of input signals, including 4–20 mA, 0–10 V, and other standard analog signals, for seamless integration with various types of sensors and transmitters

• High Accuracy and Resolution – Offers precise data conversion with high resolution and accuracy, ensuring the reliable transmission of process data for critical operations

• Built-in Diagnostics – Features diagnostics, including LED indicators, to easily identify faults and ensure system integrity during operation

• Robust Industrial Design – Built to withstand harsh industrial environments, ensuring long-term performance in demanding applications

• Easy Integration – Fully compatible with Honeywell’s control and safety systems, making installation and system integration straightforward

Technical Specifications

3.1 Dimensions and Weight

3.2 Electrical Characteristics

3.3 Environmental Characteristics

3.4 System Compatibility

Industry Applications

• Process Control – Used for monitoring critical process variables such as temperature, pressure, and flow in chemical, petrochemical, and pharmaceutical plants

• Power Generation – Facilitates accurate data acquisition from field devices in turbine and generator systems, supporting energy optimization and system stability

• Oil & Gas – Monitors sensors such as pressure transmitters and temperature gauges, essential for safe and efficient oil and gas production and distribution

• Water/Wastewater Treatment – Ensures precise measurement of flow, pressure, and chemical concentrations, contributing to the optimal operation of water and wastewater treatment plants

• Building Automation – Interfaces with environmental sensors such as temperature and humidity sensors to manage HVAC systems and energy consumption efficiently

The Honeywell CC-GAIC21 Analog Input Module offers a reliable and accurate solution for converting analog signals into digital data for industrial automation and control systems. Its flexibility, high accuracy, and diagnostics capabilities make it a valuable component for industrial processes that require precision and reliability.
