Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Product Name | Servo Valve Positioner Module |
| Model | CC-PSV201 |
| Part Number | 51454123-175 |
| Module Type | Servo valve control and positioning module |
| Control Signal Type | 4–20 mA control signal |
| Feedback Signal | Valve position feedback input |
| Control Accuracy | High-precision closed-loop positioning |
| Output Type | Servo drive output for valve actuator |
| Power Supply | 24 V DC (via system backplane) |
| Isolation | Signal and system isolation |
| Diagnostic Features | Valve position monitoring and fault detection |
| Redundancy Support | Supports redundant control configuration |
| Application | Industrial process control valve positioning |
| Mounting Type | Rack-mounted installation |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +85 °C |
| Dimensions | 63.5 × 124.46 × 307.34 mm |
| Weight | 0.7 kg |
FAQ
Q1: What is the primary function of the CC-PSV201 module?
A1: It controls and monitors servo valve positioning in industrial process control applications.
Q2: What type of control signal does it support?
A2: It supports standard 4–20 mA analog control signals for precise valve actuation.
Q3: Does the module support closed-loop control?
A3: Yes, it operates in a closed-loop configuration using valve position feedback.
Q4: How does the module ensure positioning accuracy?
A4: Through continuous feedback comparison and precise output adjustment to the servo actuator.
Q5: Is electrical isolation provided?
A5: Yes, signal circuits are electrically isolated from the control system to reduce interference.
Q6: What diagnostic capabilities are available?
A6: It provides valve position monitoring, signal fault detection, and internal health diagnostics.
Q7: Can it be used in redundant control systems?
A7: Yes, it supports redundant configurations for high-availability applications.
Q8: What installation practices improve reliability?
A8: Proper grounding, shielded signal wiring, stable power supply, and correct actuator calibration are recommended.
