Honeywell FC-TDOL-07120 Analog Output Modules
Product Overview
The Honeywell FC-TDOL-07120 Analog Output Module is an advanced module designed to provide accurate analog output signals for use in Honeywell’s control and automation systems. It enables precise control of field devices such as actuators, valves, and motors by converting digital control signals into corresponding analog outputs. With a high degree of accuracy, the FC-TDOL-07120 is perfect for applications requiring fine control of industrial processes, ensuring consistent and reliable performance in industries like power generation, oil and gas, and chemical processing.
Key Features
-
High-Accuracy Analog Output – Provides precise analog output with a high degree of fidelity, ensuring accurate control over field devices and enabling fine adjustments in industrial processes
-
Wide Output Range – Capable of delivering output signals in a wide range, typically 4-20 mA or 0-10 V, depending on configuration, allowing compatibility with various field devices
-
Multiple Channel Configuration – Supports multiple output channels (typically up to 8), enabling simultaneous control of multiple field devices for streamlined system integration
-
High Resolution – Offers high resolution for smooth, fine-grained control over output signals, reducing the risk of control errors and improving overall process quality
-
Temperature and Voltage Compensation – Includes built-in compensation for temperature and voltage fluctuations, ensuring stable and reliable operation in challenging environmental conditions
-
Built-In Protection – Provides built-in protection features including overload, short-circuit, and surge protection to safeguard connected equipment and improve system reliability
-
Seamless Integration – Easily integrates with Honeywell’s control systems, ensuring quick setup, minimal configuration, and high compatibility with a wide range of Honeywell products
-
Compact and Reliable – Designed to operate in harsh industrial environments, with a robust and compact design that ensures durability and long-term reliability
-
Diagnostic Capabilities – Equipped with diagnostic features that help monitor the health of the module and ensure proper operation, allowing for preventive maintenance and reducing the risk of unexpected downtime
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 240 x 109 x 71 mm |
| Weight | 0.45 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Output Range | 4-20 mA or 0-10 V (depending on configuration) |
| Output Accuracy | ±0.5% of full scale |
| Resolution | 12-bit or better |
| Power Supply | 24 VDC (nominal) |
| Power Consumption | Approx. 5 W |
| Isolation | 1500 VDC (input/output) |
| Protection | Overload, short-circuit, and surge protection |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | -20°C to +70°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Vibration | IEC 60068-2 compliant |
| Protection | IP20 (when installed in an enclosure) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Platform | Honeywell Control Systems |
| Compatibility | Compatible with Honeywell control systems and field devices |
Industry Applications
-
Power Generation – Controls the operation of actuators and valves in power plants, optimizing the performance of turbines, generators, and cooling systems
-
Oil & Gas – Enables precise control of equipment in offshore and onshore rigs, including valves and flow meters, contributing to operational efficiency and safety
-
Chemical Processing – Regulates chemical process control, ensuring accurate and stable operation of pumps, mixers, and reactors in chemical plants
-
Manufacturing – Provides reliable control of field devices like conveyors, motors, and actuators in factory automation systems, enhancing production efficiency and reducing downtime
-
Water & Wastewater Treatment – Manages water treatment processes by controlling valves, pumps, and other critical equipment, ensuring the quality and consistency of output
The Honeywell FC-TDOL-07120 Analog Output Module is a key component for precise and reliable control of field devices in Honeywell-based control systems. With its high accuracy, wide output range, and robust design, it ensures optimal performance in demanding industrial applications, including power generation, oil and gas, and manufacturing. By providing seamless integration with Honeywell systems, it contributes to operational efficiency, improves process quality, and supports predictive maintenance strategies.
