Schneider Electric 140EHC10500 – High-Speed Counter Module
Product Overview
The Schneider Electric 140EHC10500 is a high-speed counter (HSC) module designed for the Modicon Quantum automation platform. Engineered to capture fast pulse signals with microsecond-level resolution, it is ideal for applications requiring precise counting, frequency measurement, and motion monitoring. The module features four independent channels capable of handling high-frequency input signals from encoders, pulse-generating sensors, and flowmeters. Its dedicated processing and fast response make it an essential component for real-time control and motion applications.
Key Features
-
4 Independent Channels – Enables simultaneous high-speed counting or event capturing
-
High-Frequency Input Support – Accepts input signals up to 1 MHz per channel
-
Versatile Input Modes – Supports up/down, quadrature, frequency, and period measurement
-
Fast Event Processing – Designed for precise and deterministic input response
-
Built-In Diagnostics – Includes per-channel LEDs and fault reporting for easy troubleshooting
-
Quantum System Integration – Seamless configuration with Modicon Quantum CPUs via Unity Pro
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.35 kg |
3.2 Electrical Characteristics
| Item | Specification |
|---|---|
| Input Voltage Range | 5–30 VDC (typical for industrial sensors) |
| Input Frequency | Up to 1 MHz per channel |
| Number of Channels | 4 |
| Input Type | Differential or single-ended |
| Input Isolation | 1500 V RMS field-to-logic |
| Counting Modes Supported | Up/Down, A-B Quadrature, Frequency, Time Interval |
| Input Impedance | 10 kΩ typical |
3.3 Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Protection | IP20 (when installed in enclosure) |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Platform | Schneider Electric Modicon Quantum Series |
| Mounting | Standard Quantum rack/chassis |
| Configuration | Unity Pro or EcoStruxure Control Expert |
Industry Applications
-
Motion Control Systems – Interfaces with encoders for real-time position and speed tracking
-
Material Handling – Counts pulses from conveyor and drive systems for accurate movement control
-
Flow Measurement – Monitors high-frequency flowmeter signals in process industries
-
Packaging Lines – Tracks product counts and cycle speeds with precision
-
Turbine Monitoring – Captures rotational speed data in power generation applications
The Schneider Electric 140EHC10500 High-Speed Counter Module delivers precise, high-speed pulse counting and signal measurement for critical automation tasks. Its robust performance, multi-mode capability, and Quantum system compatibility make it an essential component in advanced industrial control systems.
Schneider 140EHC10500 High-speed Counter Module is in stock. Please contact us for a quick quote and competitive pricing.
