Product Introduction
The Schneider 140ERT85410 is a Multifunction Input Module designed for the Modicon Quantum automation platform. This module offers 32 discrete inputs, accommodating a voltage range of 24 to 125 V DC, making it versatile for various industrial applications. It features advanced functionalities such as status logging, event counting up to 500 Hz, and time-stamped event logging, ensuring precise monitoring and control within automation systems. Additionally, it supports time synchronization via the DCF77 protocol, enhancing the accuracy of time-sensitive operations.
Product Specifications
| Specification | Details |
|---|---|
| Model Number | 140ERT85410 |
| Function | Multifunction Input Module |
| Number of Inputs | 32 discrete inputs |
| Input Voltage Range | 24 to 125 V DC |
| Switching Voltage | – 24 V: 6 mA – 48 V: 2.5 mA – 60 V: 2.5 mA – 125 V: 1 mA |
| Input Current | 5 mA (clock signal input) |
| Acquisition Time | 1 ms (clock signal input) |
| Anti-Bounce Filtering | Configurable from 0 to 255 ms |
| Time Synchronization Protocol | DCF77 |
| Power Consumption | 7.5 W (process input) |
| Current Consumption | – 0.07 mA at 24 V DC (140XCP90000 module) – 3 mA at 24…125 V DC (external power supply per group of channels) – 300 mA at 5 V DC (bus) |
| Insulation | By optocoupler (clock signal input and between groups of channels) |
| Electrical Connection | – Shielded cable: <600 m (process input) – Unshielded cable: <400 m (process input) |
| Local Signaling | – 1 green LED for communication on the bus (Active) – 1 green LED for self-test OK, module ready (R) – 1 red LED for fault (F) – 32 LEDs for status of inputs (1 to 32) |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 95% without condensation |
| Operating Altitude | ≤ 5000 m (16404.2 ft) |
| Protective Treatment | TC |
| Certifications | – CSA – UL – C-tick – GOST – Merchant Navy |
| Dimensions (H x W x D) | 103.9 × 40.3 × 250 mm |
| Weight | 0.45 kg |
Product Applications
The Schneider 140ERT85410 Multifunction Input Module is utilized across various industries to enhance automation and control systems. Its applications include:
- Manufacturing Plants: Monitoring and logging discrete input signals from machinery to ensure operational efficiency and timely maintenance.
- Energy Sector: Integrating into power generation and distribution systems for real-time status monitoring and event logging.
- Water Treatment Facilities: Supervising pump operations and valve positions to maintain optimal water processing and distribution.
- Transportation Systems: Managing signals from various sensors in railways and subways to ensure safety and reliability.
- Building Automation: Controlling and monitoring HVAC systems, lighting, and security systems for efficient building management.
Product Advantages
- Versatile Input Voltage Range: Accommodates a wide range of input voltages (24 to 125 V DC), offering flexibility in various applications.
- High-Speed Event Counting: Capable of counting events up to 500 Hz, suitable for applications requiring rapid signal processing.
- Time-Stamped Event Logging: Provides precise time-stamped logs of events, essential for accurate monitoring and troubleshooting.
- Configurable Anti-Bounce Filtering: Allows customization of input signal filtering (0 to 255 ms) to eliminate noise and false triggering.
- Time Synchronization: Supports DCF77 protocol for accurate time synchronization across the automation system.
- Robust Design: Built to withstand industrial environments with high humidity (up to 95% without condensation) and operating altitudes up to 5000 meters.
- Comprehensive Diagnostics: Equipped with LEDs for real-time status indication, facilitating quick diagnostics and maintenance.
- Compliance with Standards: Certified by CSA, UL, and GOST, ensuring adherence to international safety and quality standards.
- Compatibility: Seamlessly integrates with the Modicon Quantum automation platform, enhancing system scalability and functionality.
- Energy Efficient: Low power consumption (7.5 W), contributing to overall energy savings in industrial operations.
Recommended Models
| Model Number | Description |
|---|---|
| 140ERT85410Z | Enhanced Multifunction Input Module with additional diagnostic capabilities and CRC checks for improved reliability. |
| 140DDI35300 | 32-Channel 24 V DC Discrete Input Module, suitable for high-density input applications. |
| 140DDI84100 | 16-Channel 24 V DC Discrete Input Module with positive logic, ideal for standard input requirements. |
| 140DDO35300 | 32-Channel 24 V DC Discrete Output Module, complementing input modules for comprehensive control. |
| 140DDO84300 | 16-Channel 24 V DC Discrete Output Module with positive logic, ensuring reliable output control. |
| 140ACO13000 | 4-Channel Analog Output Module, providing precise analog signal control for various applications. |
| 140ACI03000 | 8-Channel Analog Input Module, enabling accurate analog signal monitoring. |
| 140CPU65150 | Quantum CPU with 3072 kB memory, offering high-performance processing capabilities. |
| 140CPS11420 | Power Supply Module with 115/230 V AC input, ensuring stable power for the automation system. |
| 140NOE77101 | Ethernet Communication Module, facilitating network connectivity and data exchange. |
Schneider 140ERT85410 Multifunction Input Module Rave reviews is in stock. Please contact us for a quick quote and competitive pricing.
