Schneider 170AAI52040 Distributed Analog Input Base

Product Overview
The Schneider 170AAI52040 Distributed Analog Input Base is a modular I/O system designed to provide high-precision analog signal input for industrial automation and control systems. This module is part of Schneider Electric’s Modicon range of distributed I/O systems and is designed to handle up to 16 analog input channels, providing reliable and scalable solutions for applications that require high accuracy and efficient integration. With its flexible configuration and robust performance, the 170AAI52040 is ideal for use in a wide range of industrial environments, including manufacturing, process control, and energy management systems.

Key Features

• 16 Analog Inputs – Supports up to 16 analog input channels for a wide range of sensor types, including voltage and current signals.

• High Accuracy – Offers high-precision analog-to-digital conversion with low drift, ensuring accurate signal measurement over time.

• Modular Design – Part of a scalable modular system that can be easily integrated into existing automation networks and expanded as needed.

• Wide Input Range – Supports both voltage (0-10 V) and current (4-20 mA) input ranges, making it compatible with a variety of industrial sensors.

• Remote I/O Capability – Enables remote I/O functionality for distributed control systems, minimizing the need for centralized I/O processing.

• LED Status Indicators – Features built-in LEDs for each channel, providing clear status indicators for signal integrity and troubleshooting.

• High Reliability – Designed for harsh industrial environments, with rugged construction and long-term durability.

Technical Specifications

3.1 Dimensions and Weight

3.2 Electrical Characteristics

3.3 Environmental Characteristics

3.4 System Compatibility

Industry Applications

• Manufacturing Automation – Ideal for monitoring analog signals from industrial sensors such as pressure transducers, temperature sensors, and flow meters in production environments.

• Process Control – Used in industries like chemical processing, pharmaceuticals, and food manufacturing, where precise analog input is needed for controlling process variables like temperature, pressure, and level.

• Energy Management – Suitable for collecting data from energy meters, voltage/current sensors, and other energy monitoring devices in power distribution systems.

• Water and Wastewater – Perfect for collecting analog signals from water quality sensors, flow meters, and level sensors in water treatment plants.

• Oil & Gas – Enables the monitoring and control of equipment such as pumps, valves, and turbines in harsh oil and gas environments.

The Schneider 170AAI52040 Distributed Analog Input Base offers a highly flexible and reliable solution for integrating analog sensors into distributed control systems. Its modular design, high-precision analog signal processing, and compatibility with various field devices make it an essential component for optimizing automation and control processes across various industries.
