Schneider 170AEC92000 Distributed Analog/Discrete I/O Modules
__________________________________________________________________________________________
Product Overview
The Schneider 170AEC92000 is a versatile Distributed Analog/Discrete I/O Module designed for use within the Modicon Momentum automation platform. This module allows for the integration of both analog and discrete I/O points within a compact and flexible configuration, enabling efficient data collection and control in a wide variety of industrial applications. The 170AEC92000 module is ideal for distributed I/O architectures where space-saving and modularity are critical, making it a powerful solution for expanding system capabilities without complex wiring or additional PLCs.
Key Features
-
Dual I/O Functionality: Supports both analog and discrete I/O channels, offering flexibility and reduced hardware requirements.
-
Modicon Momentum Compatibility: Fully compatible with the Modicon Momentum system, facilitating seamless integration and configuration.
-
Compact Form Factor: Space-efficient design for use in control panels with limited space.
-
Hot Swap Capability: Modules can be replaced without shutting down the system, minimizing downtime during maintenance.
-
Built-in Diagnostics: Provides real-time monitoring of I/O status and module health, simplifying troubleshooting and maintenance.
-
Wide Operating Temperature Range: Engineered to perform reliably in various industrial environments.
-
DIN Rail Mounting: Easy installation and secure fitment in standard enclosures.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 47.5 x 125 x 141.5mm |
| Weight | 0.24 kg |
3.2 Module Information
| Item | Specification |
|---|---|
| Model Number | 170AEC92000 |
| Module Type | Distributed Analog/Discrete I/O Module |
| Mounting | DIN rail or base mounted with Momentum base |
| I/O Type | Mixed analog and discrete |
3.3 Electrical and Physical Characteristics
| Item | Specification |
|---|---|
| Supply Voltage | 24 V DC nominal |
| Analog Input Range | 0–10 V or 4–20 mA |
| Discrete Input Type | Sink or source configurable |
| Output Type | Digital (relay or transistor options) |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -40°C to +85°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
3.4 System Compatibility
| Item | Specification |
|---|---|
| Compatible System | Schneider Modicon Momentum |
| Communication Interface | Ethernet or Modbus via communication adapter |
| Software Configuration | Concept, Unity Pro, or EcoStruxure Control Expert |
Industry Applications
-
Factory Automation: Enables real-time monitoring and control of both analog sensors and discrete switches in automated production lines.
-
Process Control: Integrates seamlessly into process industries such as food and beverage, pharmaceuticals, and chemical manufacturing.
-
Infrastructure Management: Ideal for building automation systems, managing lighting, HVAC, and other facility control devices.
-
Water and Wastewater: Provides distributed control capabilities in treatment plants for pumps, valves, and instrumentation.
-
Energy Management: Assists in the monitoring and control of energy meters and load control devices for optimized energy usage.
The Schneider 170AEC92000 Distributed Analog/Discrete I/O Module is a compact, reliable, and flexible solution for managing mixed I/O in modern industrial environments. Its integration with the Modicon Momentum platform and dual-function I/O capability makes it a valuable asset in streamlining automation architecture and reducing installation complexity.
