Product Overview
The Schneider ABE7H16C31 Passive Connection Sub Base is an essential component in Schneider Electric’s range of modular connection bases designed for use in industrial automation systems. This passive connection sub base plays a critical role in simplifying the wiring and connection of electrical devices, ensuring the seamless integration of modular components. It provides a secure and reliable platform for connecting various devices, such as input/output modules, relays, and other control systems. The ABE7H16C31 sub base is a key part of Schneider Electric’s efforts to deliver modular, flexible, and easy-to-install solutions that can be adapted to different applications and system configurations.
This sub base is part of the Schneider Electric Modicon range, a family of products known for their robustness, ease of use, and high compatibility. By using this passive connection sub base, users can benefit from a cost-effective solution for system assembly, as well as simplified installation and maintenance processes.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | Schneider ABE7H16C31 |
| Type | Passive Connection Sub Base |
| Number of Slots | 16 slots |
| Mounting Type | DIN Rail Mount |
| Connection Type | Spring-loaded, screw-less connections |
| Rated Voltage | 24 VDC to 240 VAC |
| Rated Current | 10 A per terminal |
| Rated Frequency | 50/60 Hz |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions (W x H x D) | 106 × 63 × 64 mm |
| Weight | 0.26 kg |
| Material | High-quality thermoplastic, flame-retardant |
| Protection | IP20 protection |
| Compatible Modules | Compatible with Schneider Electric Modicon I/O modules and relays |
| Installation | Easy snap-in installation on DIN rail |
Applications of the Schneider ABE7H16C31
The Schneider ABE7H16C31 Passive Connection Sub Base is used extensively in a variety of industrial and automation applications. Some key areas where this product is applied include:
-
Industrial Automation Systems: The sub base is used to organize and securely mount I/O modules, relays, and other control devices, making it ideal for use in large-scale automation projects where modularity and flexibility are important.
-
Control Panels: It is widely employed in control panels, offering a structured and efficient way to manage the wiring of different automation and control components. The sub base provides easy access for maintenance and troubleshooting.
-
Building Management Systems (BMS): The sub base plays an important role in building management systems, allowing for the integration of control modules related to lighting, HVAC (Heating, Ventilation, and Air Conditioning), and other building automation functions.
-
Energy Management: In energy management applications, the sub base supports the interconnection of sensors, meters, and controllers used in smart grids and energy monitoring systems.
-
Process Control: The ABE7H16C31 is used in process control applications, where it helps connect sensors, actuators, and controllers, ensuring seamless data flow and control of industrial processes.
-
OEM Applications: Original Equipment Manufacturers (OEMs) benefit from this sub base when designing automation systems for specific machinery, where the ease of integration and scalability is crucial.
Advantages of Schneider ABE7H16C31
-
Modular and Flexible: The ABE7H16C31 sub base offers the flexibility to connect a wide range of modules and devices. Its 16 slots enable a modular configuration, which can be easily adjusted to meet the needs of different applications.
-
Space-Efficient Design: With compact dimensions of 106 × 63 × 64 mm, this sub base can be installed in tight spaces, making it an excellent solution for systems with limited panel space.
-
Reliable and Durable: The sub base is constructed from high-quality thermoplastic material, ensuring it can withstand harsh industrial environments. It is also flame-retardant for enhanced safety.
-
Easy Installation and Maintenance: Featuring spring-loaded, screw-less connections, the ABE7H16C31 simplifies installation by eliminating the need for screw tightening, reducing wiring time, and increasing the overall reliability of the connection.
-
Cost-Effective: As a passive connection solution, the ABE7H16C31 offers an affordable option for organizations looking to optimize their industrial automation systems without compromising on performance.
-
Compatibility with Schneider Electric Products: Designed to work seamlessly with Schneider Electric’s Modicon I/O modules, this sub base ensures compatibility and smooth integration within existing systems, streamlining the setup process.
-
Wide Operating Temperature Range: The sub base operates efficiently in temperatures ranging from -20°C to 60°C, ensuring reliability even in challenging environmental conditions.
-
Safety: The sub base provides IP20 protection, ensuring the safety of both users and equipment by preventing accidental contact with live parts.
Related Models
| Model Name | Description | Key Features |
|---|---|---|
| Schneider ABE7H08C31 | 8-slot passive connection sub base | Compact 8-slot design, same quality and features |
| Schneider ABE7H32C31 | 32-slot passive connection sub base | High capacity with 32 slots for larger systems |
| Schneider ABE7H16C01 | 16-slot passive connection sub base for I/O modules | Standard 16-slot option, designed for standard automation needs |
| Schneider ABE7H16C02 | 16-slot passive connection sub base with enhanced connectivity | Improved connection options for better flexibility |
| Schneider ABE7H16C04 | 16-slot passive connection sub base with additional features | Includes higher rated current and voltage specifications |
| Schneider ABE7H24C31 | 24-slot passive connection sub base with DIN rail mounting | Offers extra slots and scalability for larger configurations |
| Schneider ABE7H08C01 | 8-slot passive connection sub base with screw connections | Basic 8-slot version for cost-sensitive projects |
| Schneider ABE7H16C05 | 16-slot passive connection sub base with enhanced protection | Provides additional safety and protection features |
| Schneider ABE7H16C33 | 16-slot passive connection sub base with communication ports | Designed for applications requiring communication capabilities |
| Schneider ABE7H16C40 | 16-slot passive connection sub base with optimized wiring options | Optimized wiring design for ease of installation |
Schneider ABE7H16C31 Passive Connection Sub Base Intimate service is in stock. Please contact us for a quick quote and competitive pricing.
