Product Overview

The Schneider ABE7H16R11 Passive Connection Sub Base is an integral part of the Schneider Electric Modicon I/O systems. Designed for industrial automation and control systems, this passive connection sub base offers a reliable, cost-effective solution for connecting various control and input/output modules. It plays a critical role in organizing and managing the electrical connections in automation panels, ensuring a streamlined and efficient installation process. The ABE7H16R11 is designed with flexibility and durability in mind, making it ideal for a wide range of applications across different industries.

This sub base is part of Schneider Electric’s range of modular DIN rail-mounted components, which offer a modular, customizable approach to industrial automation. It ensures that your system connections are organized, secure, and easy to access for future maintenance and upgrades.

Product Specifications

Applications of the Schneider ABE7H16R11

The Schneider ABE7H16R11 Passive Connection Sub Base is highly versatile and used in various industrial automation applications. Some key areas where this product excels include:

• Industrial Automation Systems: The sub base is used to interconnect input/output modules, relays, and other control components, making it a core component in large-scale industrial automation systems.

• Control Panels: The sub base is commonly integrated into control panels in manufacturing plants, energy management systems, and other industrial applications, enabling efficient and organized connections between different modules.

• Building Automation: It plays an essential role in building automation systems, where it helps manage connections between control modules related to HVAC (Heating, Ventilation, and Air Conditioning), lighting, and other building systems.

• OEM Applications: Original Equipment Manufacturers (OEMs) use the sub base when developing tailored solutions for various industries, enabling flexibility in system design and integration.

• Energy Management: The ABE7H16R11 is also used in energy management systems to connect control modules and meters, helping monitor and manage energy consumption effectively.

• Process Control: This sub base is ideal for process control systems, where it connects various control and monitoring devices for managing complex industrial processes.

Advantages of Schneider ABE7H16R11

• Modular and Flexible: The ABE7H16R11 sub base offers a highly flexible and modular design, with 16 slots that can accommodate a variety of input and output modules. This modular approach allows for easy customization of systems, based on specific project needs.

• Compact Design: With a 125 x 70 x 67 mm form factor, the sub base is compact and space-efficient, making it suitable for installation in tight spaces within control panels or industrial cabinets.

• Easy Installation and Maintenance: Featuring spring-loaded, screw-less connections, this sub base simplifies the installation process, reducing wiring time and minimizing the risk of connection errors. The easy-to-install design also ensures quick maintenance when required.

• Reliable and Durable: Built from high-quality thermoplastic, the ABE7H16R11 sub base is designed to withstand harsh industrial conditions. It is also flame-retardant, enhancing safety in demanding environments.

• Wide Operating Temperature Range: The sub base operates effectively in temperatures ranging from -20°C to 60°C, making it suitable for a broad range of environments, from freezing cold to warm industrial settings.

• Safety and Protection: With an IP20 protection rating, the sub base ensures that the connected components are safeguarded from dust and accidental contact, ensuring safety during installation and operation.

• Compatibility with Schneider Electric Systems: The ABE7H16R11 is fully compatible with Schneider Electric’s Modicon I/O modules and relays, ensuring seamless integration into existing systems without compatibility concerns.

• Cost-Effective Solution: As a passive connection sub base, it provides an economical way to connect various components in industrial systems, reducing both upfront costs and maintenance costs over time.
