Product Introduction

The Schneider ABE7R16T230 is a reliable and high-quality sub-base designed for use with Schneider Electric’s range of plug-in electromechanical relays. As part of the Zelio Relay series, the ABE7R16T230 provides an effective solution for integrating electromechanical relays into various automation and control applications. The sub-base ensures secure and reliable relay installation and simplifies the process of replacing or maintaining relays without disrupting the rest of the system.

Designed to handle a wide range of industrial control applications, the ABE7R16T230 is known for its robust construction, ease of use, and compatibility with different relay types and voltages. Its compact, user-friendly design allows for easy installation on standard DIN rails, making it suitable for both new and existing control systems. The sub-base supports various input voltages and ensures smooth integration into a wide variety of automation systems, from building management to industrial machinery.

This sub-base module, when paired with the appropriate relay, provides an efficient and reliable solution for controlling electrical circuits in demanding industrial environments. Whether you are controlling motors, lighting systems, or automation processes, the ABE7R16T230 sub-base offers a secure, easy-to-maintain, and dependable platform for your relay needs.

Product Specifications

Product Applications

The Schneider ABE7R16T230 sub-base with plug-in electromechanical relay is versatile and can be used across a wide range of industrial applications. Below are some typical areas where the ABE7R16T230 is applied:

• Industrial Automation: Essential in controlling various machines, systems, and sensors in automated production lines and robotic systems.

• Building Automation: Used in HVAC control, lighting, and energy management systems, where the relay facilitates efficient and automated switching.

• Control Panels: Ideal for integration into control panels for managing electrical circuits, including alarms, lighting, and other essential functions.

• Power Distribution Systems: Plays a key role in controlling and managing electrical power distribution in plants and other large facilities.

• Machine Control: Used for controlling industrial machines such as pumps, conveyors, and motors, ensuring smooth and uninterrupted operation.

• Energy Management: Regulates power consumption by controlling equipment such as compressors, pumps, and other energy-intensive machinery.

• Motor Control Centers: Used in motor control centers to enable smooth operation and safe switching of motors in large industrial applications.

• Electronics and Electrical Systems: Provides efficient relay switching for various electrical circuits, ensuring reliable operation and maintenance.

Product Advantages

The Schneider ABE7R16T230 sub-base with electromechanical relay offers several advantages that make it a preferred choice for industrial automation and control systems:

1. Easy Installation: The sub-base is designed for quick and easy installation on DIN rails, making it suitable for a wide range of control systems, whether retrofitting or integrating into new installations.

2. High Durability: Built with high-quality materials that can withstand the rigors of industrial environments, including high vibration, dust, and humidity, ensuring long-term reliability.

3. Compact Design: With its space-saving dimensions, the ABE7R16T230 sub-base can be easily integrated into control panels and other compact electrical setups.

4. Wide Voltage Compatibility: The sub-base is compatible with a variety of voltages (230V AC), making it versatile for different industrial applications.

5. Reliable Performance: Provides high switching capacity (16A at 250V AC), enabling control of high-power electrical circuits safely and reliably.

6. Safety Compliance: Certified with CE, UL, and CSA, the ABE7R16T230 ensures that it meets the highest standards of electrical safety and performance.

7. Flexibility: Designed for use with both normally open (NO) and normally closed (NC) contacts, providing flexibility in system configurations.

8. Maintenance-Friendly: The plug-in relay design allows for easy maintenance and replacement without affecting the rest of the control system.

9. Effective Power Management: Ideal for regulating high-power devices such as motors and pumps, ensuring the efficient operation of the entire system.

10. Enhanced Efficiency: The sub-base’s reliability and ease of use contribute to more efficient system operations, reducing downtime and improving overall productivity.
