Schneider ATV650D11N4E Variable-Speed Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | ATV650D11N4E |
| Product Type | Variable-Speed Drive |
| Product Series | Altivar Process ATV650 |
| Drive Type | Variable Frequency Drive (VFD) |
| Application Type | Industrial process and utility applications |
| Rated Motor Power | 11 kW / 15 HP |
| Heavy-Duty Motor Power | 7.5 kW |
| Supply Voltage | 380–480 VAC |
| Supply Phase | 3-phase |
| Supply Frequency | 50–60 Hz |
| Output Phase | 3-phase |
| Rated Output Current | Approximately 23.5 A at 4 kHz under normal-duty conditions |
| Heavy-Duty Continuous Output Current | Approximately 16.5 A at 4 kHz |
| Maximum Transient Current | Approximately 25.9 A for 60 seconds under normal-duty conditions |
| Output Frequency | 0.1–500 Hz |
| Compatible Motor Type | Three-phase asynchronous and synchronous motors |
| Motor Control | Variable-frequency motor control |
| Control Modes | Variable torque, optimized torque, constant torque and related control modes |
| EMC Filter | Integrated EMC filter for applicable C2/C3 installations |
| Communication | Modbus TCP and Modbus Serial |
| Safety Function | Safe Torque Off (STO) |
| Safety Level | SIL 3 |
| Protection Rating | IP55 |
| Cooling Method | Forced-air cooling |
| Installation | Vertical wall-mounted installation |
| Typical Applications | Water treatment, wastewater treatment, mining, oil and gas, food and beverage, and industrial process equipment |
| Overload Capability | Supports normal-duty and heavy-duty operation according to configured application requirements |
| Maintenance | Check cooling airflow, fans, terminals, motor cables, load conditions and fault history |
| Replacement Requirement | Confirm motor power, supply voltage, load type, control mode, communication configuration and installation conditions |
| Dimensions | 264 × 678 × 330 mm |
| Weight | 19.6 kg |
FAQ
1. What is the main function of the Schneider ATV650D11N4E?
The ATV650D11N4E is a variable-speed drive from the Altivar Process ATV650 series. It controls motor speed, output frequency and torque for industrial process applications such as water treatment, pumping, ventilation and material handling.
2. What motor power is supported by the ATV650D11N4E?
The ATV650D11N4E is rated for motors up to 11 kW or 15 HP under normal-duty conditions. For applications with higher starting torque or continuous overload requirements, the heavy-duty rating should be checked before selection.
3. What power supply does the ATV650D11N4E require?
The drive uses a 380–480 VAC, three-phase power supply with a typical frequency range of 50–60 Hz. The incoming voltage should be verified before installation to ensure compatibility with the drive.
4. What types of motors can the ATV650D11N4E control?
The drive can be used with three-phase asynchronous and synchronous motors. Motor identification and control parameters should be configured according to the motor nameplate data and the characteristics of the connected load.
5. How should an overcurrent fault on the ATV650D11N4E be diagnosed?
Check the motor output wiring for short circuits or ground faults first. Then inspect the mechanical load for abnormal resistance, verify acceleration and deceleration times, and confirm that the motor rated current and drive parameters are correctly configured.
6. What should be checked if the ATV650D11N4E overheats during operation?
Check the cooling fans and ventilation paths, verify that the ambient temperature is within the permitted range, and make sure the drive is not continuously operating above its rated load. Dust or obstructions around the cooling system should also be removed.
7. How can communication problems with the ATV650D11N4E be troubleshot?
Check the Modbus TCP or Modbus Serial connection, communication cables, network settings and device addressing. Confirm that the PLC or supervisory system uses compatible communication parameters and that the drive’s communication status indicates normal operation.
8. What should be verified when replacing an ATV650D11N4E?
Confirm the motor power, supply voltage, duty rating, load characteristics, motor control mode and communication requirements. The existing drive parameters, I/O wiring, protection settings and integration with the control system should also be reviewed before commissioning the replacement unit.
Schneider ATV650D11N4E Variable-Speed Drive is in stock. Please contact us for a quick quote and competitive pricing.
