Schneider ATV930C13N4 Variable Speed Drive
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | ATV930C13N4 |
| Manufacturer | Schneider Electric |
| Product Type | Variable Speed Drive (VFD) |
| Product Series | Altivar Process ATV900 |
| Drive Series | ATV930 |
| Application | Industrial Process Applications |
| Motor Compatibility | 3-Phase Asynchronous and Synchronous Motors |
| Rated Motor Power (Normal Duty) | 132 kW (175 HP) |
| Rated Motor Power (Heavy Duty) | 110 kW (150 HP) |
| Supply Voltage | 380–480V AC (-15% / +10%) |
| Supply Phases | 3-Phase |
| Supply Frequency | 50/60 Hz |
| Continuous Output Current (Normal Duty) | 260 A |
| Continuous Output Current (Heavy Duty) | 211 A |
| Line Current @ 380V | 245 A (ND), 201 A (HD) |
| Line Current @ 480V | 205 A (ND), 165 A (HD) |
| Apparent Power | 150 kVA (ND), 121.8 kVA (HD) |
| Maximum Transient Current | 312 A (ND), 316.5 A (HD) for 60 s |
| Output Frequency Range | 0–599 Hz |
| Switching Frequency | 1–8 kHz Adjustable |
| Nominal Switching Frequency | 2.5 kHz |
| Control Modes | Constant Torque, Variable Torque, Optimized Torque, Permanent Magnet Motor, Synchronous Reluctance Motor |
| Communication Protocol | Ethernet/IP, Modbus TCP, Modbus RTU |
| Optional Communication | PROFINET, Profibus DP, EtherCAT, DeviceNet, CANopen |
| Integrated Braking Chopper | Yes |
| EMC Filter | Integrated |
| Protection Rating | IP21 (Drive), IP20 Internal Components |
| Mounting Type | Wall Mount |
| Cooling Method | Forced Air Cooling |
| Digital Inputs | 10 |
| Relay Outputs | 3 |
| Operating Temperature | -15°C to +50°C (without derating) |
| Storage Temperature | -25°C to +70°C |
| Short-Circuit Rating | 50 kA |
| Dimensions (H × W × D) | 1205 × 320 × 393 mm |
| Weight | 108 kg |
| Typical Applications | Water & Wastewater, Oil & Gas, Mining, Metals, HVAC, Food & Beverage, Process Industries |
| Lifecycle Status | Active / Current Product |
FAQ
Q1: What is the ATV930C13N4 used for?
A1: It is a high-performance Altivar Process drive designed for large industrial process applications including water treatment, mining, oil & gas, HVAC systems, and manufacturing facilities.
Q2: What motor size can it control?
A2: It supports motors up to 132 kW (175 HP) in Normal Duty applications and 110 kW (150 HP) in Heavy Duty applications.
Q3: Does it include a braking unit?
A3: Yes. The ATV930C13N4 includes an integrated braking chopper for dynamic braking applications.
Q4: Which communication protocols are built in?
A4: Ethernet/IP, Modbus TCP, and Modbus RTU are integrated as standard communication interfaces.
Q5: What protection rating does it have?
A5: The drive has an IP21 enclosure rating with IP20 internal protection.
Q6: What are the dimensions and weight?
A6: The unit measures 1205 × 320 × 393 mm and weighs approximately 108 kg.
Q7: What motor technologies are supported?
A7: It supports asynchronous motors, permanent magnet motors, and synchronous reluctance motors with advanced energy optimization features.
Q8: Is the ATV930C13N4 still available?
A8: Yes. The ATV930C13N4 is an active member of the Schneider Electric Altivar Process ATV900 family and remains in current production.
Schneider ATV930C13N4 Variable Speed Drive is in stock. Please contact us for a quick quote and competitive pricing.
