Schneider BMXDDO3202K Discrete Output Module
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | BMXDDO3202K |
| Manufacturer | Schneider Electric |
| Product Family | Modicon X80 |
| Product Type | Discrete Output Module |
| Output Channels | 32 Digital Outputs |
| Output Type | Relay |
| Output Voltage | 24 VDC |
| Output Current | 0.5 A per channel (max) |
| Output Logic | Positive Logic (Sink/Source Compatible) |
| Output Protection | Short-Circuit and Overload Protection per Channel |
| Response Time | ≤ 2 ms |
| Isolation | Channel-to-Bus Isolation |
| Status Indicators | 32 Channel LEDs + Module Status LED |
| Power Supply | Via Modicon X80 Backplane |
| Current Consumption | Approx. 100 mA @ 3.3 VDC |
| Power Dissipation | Approx. 3 W |
| Connection Type | 40-pin Removable Terminal Block |
| Compatible Platforms | Modicon M340, Modicon M580, Modicon X80 Systems |
| Mounting Method | Installed in Modicon X80 Rack |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% Non-Condensing |
| Shock Resistance | 30 gn |
| Dimensions (H × W × D) | Approx. 100 × 64 × 86 mm |
| Weight | Approximately 0.35 kg |
| Standards Compliance | IEC 61131-2 |
| Typical Applications | Digital Output Control, Industrial Automation, Machine Control, Process Control |
| Lifecycle Status | Active / Current Product |
FAQ
Q1: What is the BMXDDO3202K used for?
A1: It is a 32-channel 24 VDC relay digital output module for Schneider Electric Modicon X80 PLCs, used to switch discrete loads such as relays, lamps, or solenoids.
Q2: How many output channels are available?
A2: The module provides 32 discrete output channels.
Q3: What type of outputs does it provide?
A3: Relay outputs compatible with 24 VDC loads, each rated up to 0.5 A.
Q4: Does the module provide diagnostics?
A4: Yes. Each channel has LED indication, and the module supports status monitoring for fault detection.
Q5: How is the module powered?
A5: Power is supplied via the Modicon X80 backplane.
Q6: Which PLC systems are compatible?
A6: Modicon M340, Modicon M580, and other Modicon X80-based automation platforms.
Q7: What are the dimensions and weight?
A7: Approx. 100 × 64 × 86 mm, weighing about 0.35 kg.
Q8: Is the BMXDDO3202K still available?
A8: Yes. The BMXDDO3202K is an active Schneider Electric product in the Modicon X80 I/O family.
Schneider BMXDDO3202K Discrete Output Module is in stock. Please contact us for a quick quote and competitive pricing.
