Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Product Type | Cable Assembly |
| Model | BMXFTA300 |
| Product Range | Modicon X80 |
| Application | Modicon M340 I/O System |
| Accessory Type | Preformed cordset for Telefast ABE7 pre-wired system |
| Compatible Modules | BMXAMI0800, BMXAMI0810 |
| Compatible Sub-bases | ABE7CPA02, ABE7CPA03, ABE7CPA31, ABE7CPA31E |
| Electrical Connection | 1 × SUB-D 25 connector + 1 × 28-way removable terminal block |
| Connector Type | SUB-D 25 |
| Terminal Type | 28-way removable terminal block |
| Cable Length | 3 m |
| Dimensions | 3 m cable length |
| Main Function | Provides a preassembled connection between compatible Modicon X80 analog I/O modules and Telefast ABE7 sub-bases |
| Signal Application | Analog I/O signal connection |
| Wiring Configuration | Factory-assembled cable with predefined connector and terminal configuration |
| Installation | Direct connection between the compatible I/O module and ABE7 sub-base |
| Maintenance | Inspect the connector, terminal block, cable sheath, and wiring points for looseness, contamination, or damage |
| Replacement Requirement | Verify the model, module compatibility, sub-base, connector configuration, and cable length before replacement |
| Weight | 0.5 kg |
FAQ
1. What is the Schneider BMXFTA300 Cable Assembly?
The BMXFTA300 is a preformed cable assembly for Schneider Electric Modicon X80 I/O systems. It provides a 25-pin SUB-D connection on the ABE7 sub-base side and a 28-way removable terminal block on the module side, allowing the I/O wiring to be connected without individually fabricating the cable.
2. What is the main function of BMXFTA300?
BMXFTA300 is used to connect compatible Modicon X80 analog input modules with Telefast ABE7 pre-wired sub-bases. The factory-assembled cable simplifies cabinet wiring and helps maintain the intended signal-to-terminal arrangement.
3. Which Schneider Electric modules are compatible with BMXFTA300?
BMXFTA300 is specified for use with Modicon X80 modules BMXAMI0800 and BMXAMI0810. The complete module reference should be checked before installation because the cable’s terminal configuration must correspond to the selected I/O module.
4. Which Telefast ABE7 sub-bases can be used with BMXFTA300?
The compatible sub-base references include ABE7CPA02, ABE7CPA03, ABE7CPA31, and ABE7CPA31E. The appropriate sub-base should be selected according to the analog I/O configuration and field wiring requirements of the installation.
5. What connectors are used on BMXFTA300?
BMXFTA300 uses one 25-pin SUB-D connector on the ABE7 sub-base side and one 28-way removable terminal block on the module side. This combination provides a predefined interface between the Modicon X80 analog module and the Telefast pre-wired system.
6. What should be checked if an analog input signal is missing?
First check that the SUB-D 25 connector and 28-way terminal block are fully seated and secured. Then verify the terminal assignment, conductor continuity, field wiring, and module diagnostic status. If the cable is correctly connected, the ABE7 sub-base and connected field device should also be checked.
7. Can BMXFTA300 be replaced with another cable having the same cable length?
Cable length alone is not sufficient to determine compatibility. A replacement must have the correct SUB-D connector, 28-way terminal configuration, module compatibility, and ABE7 sub-base interface. Using a cable with a different internal wiring arrangement may result in incorrect analog channel connections.
8. How should BMXFTA300 be maintained?
Regularly inspect the SUB-D 25 connector, 28-way terminal block, cable sheath, and connection points for looseness, contamination, corrosion, or mechanical damage. For analog signal applications, also check cable routing and connection integrity to reduce the risk of signal instability caused by poor connections or electrical interference.
Schneider BMXFTA300 Cable Assemblies is in stock. Please contact us for a quick quote and competitive pricing.
