Schneider BMXNRP0201 Fiber Optic Converter
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | BMXNRP0201 |
| Product Type | Fiber Optic Converter / Fiber Optic Repeater |
| Product Family | Modicon X80 |
| Fiber Type | Single-Mode Fiber |
| Rated Voltage | 24 V DC |
| Current Consumption | 140 mA typical, 200 mA maximum |
| Ethernet Ports | 2 × RJ45, 100BASE-TX |
| Fiber Optic Ports | 2 × 100BASE-FX |
| Ethernet Standard | IEEE 802.3u |
| Wavelength | 1310 nm |
| Fiber Size | 9/125 µm |
| Maximum Operating Distance | 15 km |
| Optical Attenuation | -15 to -8 dB |
| Rise/Fall Time | 2.5 ns |
| Receiver Sensitivity | -31 to -8 dBm |
| Hot Swap | Supported |
| LED Indicators | Power, error, link, fiber status and activity |
| Mounting | Modicon X80 rack |
| Protection Rating | IP20 |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 70 °C |
| Dimensions | 32 × 100 × 86 mm |
| Weight | 0.203 kg |
FAQ
1. What is the Schneider BMXNRP0201 used for?
The BMXNRP0201 is a fiber optic converter and repeater for Modicon X80 systems. It provides communication between copper Ethernet connections and single-mode fiber links, making it suitable for extending 100 Mbps Ethernet networks between automation cabinets, control stations, and remote equipment.
2. What type of fiber does the BMXNRP0201 support?
The BMXNRP0201 is designed for single-mode fiber with a 9/125 µm fiber size. It uses a 1310 nm optical wavelength. The fiber cable and connected optical equipment should match these specifications to ensure a stable communication link.
3. What is the maximum communication distance of the BMXNRP0201?
The specified operating distance is up to 15 km for the single-mode fiber connection. The actual achievable distance depends on the complete optical link, including fiber attenuation, connector losses, splices, and the optical power budget of the installation.
4. How many Ethernet and fiber ports does the BMXNRP0201 have?
The module provides two RJ45 Ethernet ports using 100BASE-TX and two optical ports using 100BASE-FX. This configuration allows copper Ethernet segments to be connected to single-mode fiber networks within the Modicon X80 automation architecture.
5. Does the BMXNRP0201 require application programming?
The BMXNRP0201 operates as a fiber optic converter/repeater rather than as a conventional programmable I/O module. It does not require application logic programming for its basic conversion function. The module primarily handles the physical conversion and transmission of Ethernet communication between copper and fiber interfaces.
6. What should be checked if the fiber communication link is not working?
Check the power supply first, followed by the RJ45 connections and fiber connections. Verify that the correct single-mode 9/125 µm fiber is installed and that the optical connectors are properly seated and clean. The 1310 nm wavelength, fiber polarity, optical attenuation, and receiver sensitivity should also be considered. The LED indicators can help identify power, link, error, and fiber activity conditions.
7. Can the BMXNRP0201 be used for long-distance industrial Ethernet communication?
Yes. The single-mode optical interface is designed for communication distances of up to 15 km, making the BMXNRP0201 suitable for long-distance industrial Ethernet links where standard copper Ethernet cabling is insufficient. The complete network should still be evaluated for optical power margin and environmental conditions before commissioning.
8. What is the difference between BMXNRP0201 and BMXNRP0200?
The primary difference is the supported fiber type and transmission distance. BMXNRP0201 uses single-mode 9/125 µm fiber and supports distances up to 15 km, while BMXNRP0200 is designed for multimode fiber and supports a shorter distance. The correct model should therefore be selected according to the existing fiber infrastructure and required communication distance.
Schneider BMXNRP0201 Fiber Optic Converter is in stock. Please contact us for a quick quote and competitive pricing.
