Schneider HMISTO715 Touch Panel Screen
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8613666084105 | |||||||
| +8613666084105 | ||||||||
| 13666084105 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | HMISTO715 |
| Product Name | Touch Panel Screen |
| Product Series | Harmony STO & STU |
| Product Type | Human-Machine Interface (HMI) Touch Panel |
| Display Size | 4.3 inches |
| Display Type | Colour TFT LCD |
| Display Resolution | 480 × 272 pixels |
| Display Colours | 65,536 colours |
| Touch Technology | Analogue touchscreen |
| Operating System | Harmony |
| Configuration Software | EcoStruxure Operator Terminal Expert |
| Rated Supply Voltage | 12–24 V DC |
| Supply Voltage Tolerance | -10% to +20% |
| Power Consumption | 7.5 W |
| Application Memory | 26 MB |
| Backup Memory | 512 KB |
| Maximum Number of Pages | 8,999 |
| Serial Communication Interface | 1 × RJ45 serial interface supporting RS-232C/RS-485 |
| Serial Communication Speed | 2,400–115,200 bps |
| USB Interfaces | 1 × USB 2.0 Type-A host; 1 × USB 2.0 Mini-B device |
| Supported Protocols | Modbus and supported third-party protocols |
| Compatible PLC Brands | Mitsubishi, Omron, Siemens and Allen-Bradley, subject to protocol and driver compatibility |
| Backlight Type | White LED |
| Backlight Service Life | Approximately 50,000 hours |
| Brightness Adjustment | 16 levels |
| Front Panel Material | Plastic |
| Enclosure Material | PPT |
| Front Panel Protection | IP65F under specified installation conditions |
| Rear Panel Protection | IP20 |
| Operating Temperature | 0–50°C |
| Installation Method | Panel mounting with two installation fasteners |
| Compatible Panel Thickness | 1.5–6 mm |
| Panel Cutout | 112.5 × 77.5 mm; 105 × 66 mm with mounting adapter |
| Dimensions | 90.4 × 124.9 × 38.8 mm |
| Weight | 0.22 kg |
FAQ
Q1: What is the Schneider Electric HMISTO715 touch panel used for?
The HMISTO715 is a 4.3-inch HMI designed for monitoring and operating compact industrial machines and automation systems. It allows operators to view process values, check equipment status, display alarms, and interact with compatible PLCs through configurable graphical screens.
Q2: Which software is used to configure the HMISTO715?
The HMISTO715 supports EcoStruxure Operator Terminal Expert for HMI application development and configuration. Use a compatible software version and confirm the required communication drivers before transferring the project to the panel.
Q3: What communication interfaces are available on the HMISTO715?
The panel provides one RJ45 serial interface supporting RS-232C or RS-485, one USB 2.0 Type-A host port, and one USB 2.0 Mini-B device port. It supports Modbus and compatible third-party protocols when configured with the appropriate driver.
Q4: Which PLC brands can communicate with the HMISTO715?
The HMISTO715 supports communication with compatible PLCs from Mitsubishi, Omron, Siemens, and Allen-Bradley. Actual compatibility depends on the PLC model, communication protocol, software driver, and serial settings. Confirm these details before commissioning.
Q5: What power supply does the HMISTO715 require?
The HMISTO715 operates on a 12–24 V DC supply with a specified tolerance of -10% to +20%. Its power consumption is 7.5 W. Use a suitable regulated power supply and follow the manufacturer’s wiring and grounding instructions.
Q6: How should the HMISTO715 be installed in a control panel?
Prepare the panel cutout according to the installation drawing, confirm that the panel thickness is within the specified range, and secure the unit using the designated fasteners. Ensure that the front sealing surface is correctly positioned to maintain the specified protection rating.
Q7: What should be checked if the HMISTO715 cannot communicate with a PLC?
Check the serial cable, connector condition, communication speed, parity, data bits, stop bits, PLC address, and selected protocol. Confirm that the HMI project uses the correct driver. If communication remains unavailable, inspect the wiring and test the communication link using an approved diagnostic procedure.
Q8: What should be considered when replacing an existing HMISTO715?
Verify the model number, power supply requirements, communication interfaces, panel mounting arrangement, and compatibility with the existing HMI project. Confirm whether the original application can be transferred directly or needs modification. After installation, test communication, screen navigation, alarms, and control functions before returning the machine to service.
