Schneider TM5ACLPR1 10-Channel Bus Base Locking Plate
| Company Information | ||||||||
| [email protected] | ||||||||
| Mobile | +8615305023276 | |||||||
| +8615305023276 | ||||||||
| 15305023276 | ||||||||
| Add to | Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China | |||||||
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | TM5ACLPR1 |
| Product Name | 10-Channel Bus Base Locking Plate |
| Manufacturer | Schneider Electric |
| Product Type | Bus base locking plate |
| Function | Mechanically locks and secures TM5 I/O bus bases to prevent loosening |
| System Compatibility | Modicon TM5 I/O system |
| Installation Position | Mounted on TM5 I/O bus base assembly |
| Mechanical Role | Structural locking and stabilization of I/O base modules |
| Installation Method | Clip-on / mechanical fastening |
| Application | Industrial automation I/O system mechanical reinforcement |
| Material | Industrial-grade engineering plastic |
| Structure Type | Lightweight locking plate component |
| Operating Environment | Industrial control cabinet environments |
| Dimensions | 16 × 53 × 105 mm |
| Weight | 0.025 kg |
FAQ
1. What is the primary function of the TM5ACLPR1 locking plate?
The TM5ACLPR1 is designed to mechanically secure TM5 I/O bus bases in place within a Modicon TM5 system. Its main function is to prevent unintended movement, loosening, or detachment of modules caused by vibration, thermal cycling, or mechanical stress in industrial environments. By stabilizing the base structure, it ensures that all connected I/O modules maintain consistent physical alignment and reliable electrical contact over time.
2. Where is this product typically used?
This locking plate is used in Modicon TM5 distributed I/O systems developed by Schneider Electric. These systems are widely deployed in factory automation, packaging lines, material handling systems, process control applications, and other industrial environments requiring modular and scalable I/O configurations.
3. Why is a locking plate necessary in I/O bus systems?
In industrial automation systems, continuous vibration, cabinet movement, and thermal expansion can gradually loosen modular connections. A locking plate provides additional mechanical reinforcement to prevent such issues. Without it, long-term reliability may be affected due to intermittent contact or slight misalignment between modules.
4. Does the TM5ACLPR1 affect electrical performance?
The locking plate itself does not directly participate in electrical signal transmission or processing. However, it indirectly improves electrical performance by ensuring that modules remain firmly seated in their connectors, thereby reducing the risk of poor contact, signal interruption, or communication errors.
5. How is the TM5ACLPR1 installed?
The component is installed using a simple clip-on or mechanical fastening method directly onto the TM5 I/O bus base assembly. It does not require complex tools or rewiring, allowing for quick installation during system assembly or maintenance operations.
6. Does this locking plate impact system expandability?
No, the locking plate is designed to complement the modular nature of the TM5 system. It does not interfere with the addition or removal of I/O modules. Engineers can still expand or reconfigure the system without removing the structural benefit provided by the locking mechanism.
7. What are the benefits of using this locking plate in long-term operation?
Over long operational cycles, the locking plate helps maintain consistent mechanical stability, reducing wear on connectors and minimizing the likelihood of intermittent faults. This leads to lower maintenance requirements, fewer unexpected shutdowns, and improved overall system uptime in industrial environments.
8. What is the industrial value of the TM5ACLPR1?
The industrial value of the TM5ACLPR1 lies in its ability to enhance structural reliability in modular I/O systems. While it is a simple mechanical accessory, it plays an important role in ensuring long-term operational stability. By reducing mechanical stress on I/O connections, it contributes to higher system reliability, reduced maintenance costs, and improved lifecycle performance in automation applications.
Schneider TM5ACLPR1 10-Channel Bus Base Locking Plate is in stock. Please contact us for a quick quote and competitive pricing.
