Schneider TSXAEY414 Analog Input Module

Product Overview
The Schneider TSXAEY414 Analog Input Module is designed to provide high-precision analog signal acquisition for Schneider Electric PLC systems. It is optimized for reading signals from field devices such as temperature sensors, pressure transmitters, and other analog devices. With support for multiple input types and built-in signal filtering, the module offers reliable and accurate measurements, ensuring precise control and monitoring in industrial automation applications.

Key Features

• Multi-Channel Input – Provides 4 analog input channels for simultaneous signal acquisition, improving system efficiency and reducing the need for multiple modules

• Wide Input Range – Supports a variety of input signals, including 0–10 V, ±10 V, and 4–20 mA, ensuring compatibility with a broad range of industrial field devices

• High Accuracy and Resolution – Offers 12-bit resolution for precise measurements, ensuring fine control in demanding process environments

• Built-in Signal Filtering – Includes software-based filtering to reduce noise and improve signal integrity for more accurate readings

• Channel Isolation – Ensures electrical isolation between input channels, protecting the PLC from interference and improving system reliability

• Fast Data Conversion – High-speed conversion rate for real-time data monitoring and control in dynamic applications

• Diagnostic LEDs – Equipped with LED status indicators for easy monitoring of module health and quick troubleshooting

• Compact Design – Space-efficient design, suitable for integration into systems with limited panel space

Technical Specifications

3.1 Dimensions and Weight

3.2 Electrical Characteristics

3.3 Environmental Characteristics

3.4 System Compatibility

Industry Applications

• Industrial Automation – Ideal for integrating multiple analog input signals from field devices such as sensors and transmitters in factory automation systems

• Process Control – Provides accurate data acquisition for process control systems in industries such as chemicals, pharmaceuticals, and food processing

• Energy Management – Enables precise signal input for energy meters, monitoring devices, and energy management systems in industrial settings

• Building Automation – Interfaces with temperature and pressure sensors for HVAC, lighting, and other building control systems

• Machine Control – Monitors machine health and performance through data acquisition from critical analog sensors

The Schneider TSXAEY414 Analog Input Module is an essential component for accurate analog signal acquisition in Schneider Electric PLC systems. Its versatile input capabilities, high accuracy, and built-in filtering make it a reliable solution for a wide range of industrial applications, from process control to energy management.
