Schneider TSXAEY420 Analog Input Modules

Product Overview

The Schneider TSXAEY420 Analog Input Module is designed to provide accurate and reliable measurement of analog signals in industrial automation and control systems. This module is compatible with Schneider Electric’s TSX series controllers, offering seamless integration and enhanced flexibility in monitoring real-world parameters such as temperature, pressure, and flow. With its high-resolution inputs, the TSXAEY420 is ideal for applications requiring precise data acquisition and efficient control of complex processes.

Key Features

• High-Resolution Inputs – Offers precise analog-to-digital conversion, ensuring accurate measurement of input signals for reliable process monitoring and control.

• Wide Input Range – Supports a broad range of input signal types, including voltage (0-10V) and current (4-20mA), for versatile application in various industrial environments.

• High-Speed Data Acquisition – Fast sampling rate for real-time monitoring and quick response times, ensuring critical parameters are continuously tracked without delay.

• Isolation Protection – Provides galvanic isolation between input channels and system to protect against electrical noise and transients, ensuring signal integrity and safety.

• Compact Design – Space-efficient, allowing for easy installation in panel-mounted or DIN rail-mounted configurations, optimizing control cabinet space.

• Easy Integration – Fully compatible with Schneider Electric’s TSX PLC systems, providing straightforward integration into existing control architectures.

Technical Specifications

3.1 Dimensions and Weight

3.2 Electrical Characteristics

3.3 Environmental Characteristics

3.4 System Compatibility

Industry Applications

• Industrial Automation – Used in control systems to monitor analog signals from a wide range of sensors, providing critical data for process control and automation.

• Process Control – Ideal for applications requiring real-time monitoring and control of processes, such as temperature, pressure, and flow regulation in chemical or manufacturing plants.

• Building Management – Utilized in building automation systems to monitor HVAC parameters, temperature sensors, and other analog inputs for efficient management of facilities.

• Energy Management – Supports energy monitoring systems by capturing analog signals from meters and sensors, providing real-time data for energy optimization.

• Machine Automation – Used in automated machines to acquire input from sensors, ensuring precise control and performance of machines in manufacturing lines.

The Schneider TSXAEY420 Analog Input Module is a key component for providing high-precision analog measurements in industrial automation systems. Its flexibility, compact design, and fast response time make it ideal for applications requiring accurate data acquisition and seamless integration with Schneider Electric’s TSX PLC systems.
