Schneider TSXDSY16S5 Discrete Output Modules
Product Overview
The Schneider TSXDSY16S5 Discrete Output Module is designed to provide reliable and efficient control of digital output signals in industrial automation systems. Part of the Modicon Premium series, the TSXDSY16S5 module offers 16 discrete output channels for controlling various industrial equipment such as relays, motors, and valves. With its robust design, this module is ideal for applications in harsh industrial environments where reliability and high performance are crucial.
This module features high-density output terminals that maximize the use of panel space while ensuring a high level of operational flexibility. It is suitable for use in process control, automation systems, and machinery where precise and dependable output control is required.
Key Features
-
High-Density Output: Provides 16 discrete output channels in a compact design, allowing for efficient use of panel space.
-
Wide Voltage Range: Accepts output voltage ranging from 24 V DC, ensuring compatibility with various industrial systems.
-
Rugged Design: Built to withstand industrial environments with protection against electrical noise, vibration, and temperature fluctuations.
-
LED Indicators: Equipped with status LEDs for each output, enabling quick and easy monitoring of module health and output status.
-
Efficient Wiring: Designed to simplify wiring, reducing installation time and potential for wiring errors.
-
Hot Swappable: Allows for replacement of the module without system shutdown, improving system uptime and maintenance efficiency.
-
Compact and Modular: Easily integrates into existing systems, providing flexible options for both new and retrofitted installations.
Technical Specifications
3.1 Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | Package size:55 × 180 × 260 mm |
| Weight | 0.31 kg |
3.2 General Information
| Item | Specification |
|---|---|
| Model | TSXDSY16S5 |
| Manufacturer | Schneider Electric |
| Installation | Panel Mount / DIN Rail Mount |
| Power Supply | 24 V DC |
| Operating Temp | 0°C to +60°C |
| Storage Temp | -20°C to +70°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
3.3 Output Performance
| Item | Specification |
|---|---|
| Output Voltage | 24 V DC |
| Output Channels | 16 discrete outputs |
| Output Current | Max 0.5 A per channel |
| Switching Frequency | Up to 10 Hz |
| Load Type | Inductive and Resistive |
| Protection | Short-circuit and overcurrent |
3.4 Electrical Characteristics
| Item | Specification |
|---|---|
| Power Consumption | Max 5 W |
| Current Draw | Max 0.2 A |
| Status Indicators | LEDs for output status |
Industry Applications
-
Manufacturing Automation: Controls automated systems such as assembly lines, packaging machines, and robotic arms.
-
Process Control: Used in process industries like oil & gas, petrochemicals, and pharmaceuticals for controlling valves and other actuators.
-
Material Handling: Provides outputs for conveyor belts, sorters, and other material handling systems.
-
HVAC Systems: Controls actuators and other devices in heating, ventilation, and air conditioning systems.
-
Building Automation: Controls lighting, access systems, and other building management systems.
-
Energy Management: Supports smart grid and energy distribution systems for efficient management of electrical output.
The Schneider TSXDSY16S5 Discrete Output Module is a versatile and reliable solution for controlling outputs in a variety of industrial applications. Its compact design, high-density terminals, and robust construction make it ideal for demanding environments requiring high-performance automation.
